Professional wood hammer crusher
Material of wood hammer crusher :
Wood chips ,wood waste ,straw ,palm fiber ,all biomass material ,after crushed the material would be sawdust or powder shape ,which can make pellet or briquette .
Wood chips
Finished sawdust (1-10mm) :
Specification of wood hammer crusher
Model |
FM50-4 |
FM60-6 |
FM80-8 |
FM80-12 |
FM90-15 |
Power(kw) |
22 |
37+7.5 |
55+11 |
90+15 |
132+15 |
Capacity(t/h) |
1 |
1-1.2 |
1.5-2 |
2-3 |
4-5 |
Dimension(m) |
1.4*0.8*1.25 |
1.8*0.9*1.6 |
2.2*1.8*1.5 |
2.3*2.3*1.5 |
2.5*2.6*2.2 |
Weight(kg) |
300 |
900 |
1100 |
2100 |
2900 |
Working principle
Material feed by manual or by belt conveyor to the mouth of hammer crusher ,the hammer (Hammer on plate)rotation and crush the wood chips until it small than the hole of screen ,then sawdust come out from the hammer crusher .
Double mouth multifunction hammer crusher
Big wood waste hammer crusher
