2.4 - 2.45 GHz directional recognition active rfid reader
1.Product Characteristics
Support RS485 mode and PC communication;
Encryption calculation and certification, to ensure data security and prevent link eavesdropping and data to crack;
Controllable operating range, up to 32 power control; adjust the reader receiving distance by commanding.
Able to identify the tags with moving speed in 60 km/h
Simultaneously identify 200 cards
Use channel isolation technology, Multiple devices do not interfere with each other
Advanced anti-collision technology to support multi-tag reading and writing;
Microwave modules can be configured to work, adjustable transmit power;
Compatible card provided by the customer.
Meet the requirements of the industrial environment
2. Physical Characteristics
Shell material: plastic front, rear aluminum
Weight: 2.5kg
Color: white gray
Shape: 320 * 200 * 100mm
Protection: IP65
Installation: mounting bracket, mounting
3. Electrical Characteristics
Operating voltage: + 9V to + 12V DC (MAX 1000mA)
Operating Current: <1000mA
Reliability: MTBF≥70000 hours
Working life:> 15 years
Communication interface: RS485
4. Microwave Link Features
Modulation: GFSK
Operating Frequency: 2.4 - 2.45 GHz
Receiving sensitivity: ≤-93dBm (available send commands to adjust)
Antenna Polarization: Vertical
Recognition range: directional recognition
Microwave communication distance: 0 ~ 100 meters
Microwave communication error detection: CRC16 cyclic redundancy check
Bit error rate /B.E.R:10-7
Communication encryption: according to customer requirements
5. Work Environment
1) interference and lightning protection designed to meet the requirements of the industrial environment
2) Operating temperature: -20 ℃ ~ + 80 ℃
3) Storage Temperature: -40 ℃ ~ + 100 ℃
4) Anti-electromagnetic interference: 10V / m 0.1-1000MHz AM amplitude electromagnetic wave
6. Applications
Tunnel installation personnel management system;
Underground mine personnel positioning management systems;
Enterprises automatic personnel access time and attendance system;
Plant personnel access control system;
Personnel access control;
Long-range identification systems;
Automatic identification of personnel management system
