Ultrasonic Probe SonicatorProbe Sonicator
Large LCD screen;
Multipurpose;
Microcomputer control
Petty-150~1800Y Ultrasonic Probe Sonicator /Processor
Description:
Ultrasonic disruptor (cell crusher) is a multipurpose instrument which is using strong ultrasonic to produce cavitations’ effect in liquid. It is able to crush animal cells, plant cells, virus cells, and also used for emulsification, separation, homogenization, extraction, deforming, cleaning and accelerating chemical reaction etc..
Features:
1. Large-screen LCD
2. Microcomputer control
3. 50-group data can be stored
4. Ultrasonic time and power can be set
5. Ultrasonic power is automatically detecting.
6. Integrated sample temperature control prevents overheating
7. Frequency is automatic tracking
8. Automatically fault alarm.
Parameters:
| Model | Frequency (KHz) | Ultrasonic power ratio | Random Amplitude Transformer | Crushing Capacity (ml) | Optional Amplitude Transformer | Temp. protection |
| Petty-150Y | 22±1 | 1%-99% | Φ6 | 0.2-200 | Φ2,Φ3 | Room Temp.~99°C |
| 5-150W | ||||||
| Petty--250Y | 1%-99% | 0.2-350 | ||||
| 10-250W | ||||||
| Petty--650Y | 1%-99% | 0.2-600 | Φ2,Φ3,Φ10,Φ12 | |||
| 10-650W | ||||||
| Petty--1000Y | 1%-99% | Φ6 / Φ10 | 0.2-1000 | Φ2,Φ3,Φ12,Φ15 | ||
| 10-1000W | ||||||
| Petty--1200Y | 19-23 | 1%-99% | Φ20 | 50-1200 | Φ12, Φ15, Φ22 | |
| 10-1200W | ||||||
| Petty--1500Y | 1%-99% | Φ20 or Φ22 | 200-1600 | Φ12, Φ15, Φ22 | ||
| 10-1500W | ||||||
| Petty--1800Y | 1%-99% | Φ20 or Φ22 | 200-2000 | Φ12, Φ15, Φ22 | ||
| 10-1800W |
Voltage: 110/220VAC,50Hz
Ultrasonic Probe
Specification:
| Model(mm) | Frequency(KHz) | Power(W) | Crusher capacity(ml) |
| Φ2 | 20-25 | 20-250 | 0.2-2ml |
| Φ3 | 30-400 | 2-5ml | |
| Φ6 | 60-650 | 5-200ml | |
| Φ8 | 80-950 | 10-300ml | |
| Φ10 | 100-950 | 10-450ml | |
| Φ12 | 19.5-20.5 | 150-950 | 15-600ml |
| Φ15 Φ20 | 400-1800 | 30-1200ml | |
| Φ25 Φ28 |
Dedicated Broken Bottle
Capacity: 50ml 100ml 400ml
