Supply Competitive Price XCMG XE215 Excavator
Save Your Money Here
Compared with the previous generation of excavators, the complete XE215CA hydraulic excavator can have its fuel consumption reduced by about 10% and its working efficiency increased by more than 5%, with its earthwork working efficiency highest among its peers. Its reinforced chassis system can have the complete excavator achieve stronger adaptability to mining conditions and a longer service life; its larger fuel tank volume increased by 15% compared with the previous generation can enable the machine to work much longer at one time, the brand-new cab subject to injection molding is configured with standard laminated glass featuring lower noise, its new air-conditioning system can have its air output increased by 23% to achieve a better warming and cooling effect as well as more comfortable operation. This machine is mainly applicable to municipal construction, highway bridges, housing construction, road engineering, construction of water conservancy works, port construction, mines, and other earthwork construction at the advantage of sufficient flexibility, good controllability, low fuel consumption, high construction efficiency, powerful digging strength, comfortable driving environment, wide range of application and other outstanding characteristics.
| Model | Unit | XE215C | |
|---|---|---|---|
| Operating weight | kg | 21450 | |
| Standard bucket capacity | m³ | 0.8~1.0 | |
| Engine | Engine Model | / | BB-6BG1TRP |
| Direct injection | / | √ | |
| Four strokes | / | √ | |
| Water cooling | / | √ | |
| Turbo charged | / | √ | |
| Air to air intercooler | / | × | |
| No. of cylinders | / | 6 | |
| Rated power/speed | kw/rpm | 106.5/1950 | |
| Max. torque/speed | N.m | 551/1600 | |
| Displacement | L | 6.494 | |
| The main performance | Travel speed | km/h | 5.5/3.3 |
| Swing speed | r/min | 13.3 | |
| Max. gradeability | / | ≥35 | |
| Ground pressure | kPa | 45.5 | |
| Max.Bucket digging force | kN | 138 | |
| Max.arm crowd force | kN | 103 | |
| Max.traction force | kN | 184 | |
| Hydraulic system | Main pump | / | 2 Plunger pump |
| Rate flow of main pump | L/min | 2×206 | |
| Max pressure of prime relief valve | MPa | 31.5/34.4 | |
| Max pressure of travel system | MPa | 34.3 | |
| Max pressure of swing system | MPa | 28 | |
| Max pressure of pilot system | MPa | 3.9 | |
| Oil capacity | Fuel tank capacity | L | 360 |
| Hydraulic tank capacity | L | 220 | |
| Engine lubrication | L | 25 | |
| Overall dimensions | A Overall length | mm | 9525 |
| B Overall width | mm | 2990 | |
| C Overall height | mm | 3000 | |
| D Overall width of upperstructure | mm | 2710 | |
| E Track length | mm | 4270 | |
| F Overall width of undercarriage | mm | 2990 | |
| G Crawer width | mm | 600 | |
| H Track length on ground | mm | 3462 | |
| I Crawer gauge | mm | 2390 | |
| J Clearance under counter weight | mm | 1050 | |
| K Ground clearance | mm | 470 | |
| L Min.tail swing radius | mm | 2750 | |
| Working range | A Max. digging height | mm | 9640 |
| B Max. dumping height | mm | 6800 | |
| C Max. digging depth | mm | 6655 | |
| D 8inch horizonal digging depth | mm | 6470 | |
| E Max. vertical wall digging depth | mm | 5695 | |
| F Max. digging reach | mm | 9925 | |
| G Min. swing radius | mm | 3530 | |
| Angle of arm deflection | Degree | ||
Spare Parts Warehouse
Reference Photos
1. According to your needs, recommend the right products with competitve price. Our company is specialized in selling Wheel loaders, Excavators, Road rollers, Heavy duty trucks, Motor graders and Tractors,etc
2. Handling exporting entire project from begining to end, from production to shipment. Sending you the documents all in full, like Bill of Loading, Invoice, Packing List etc after shipment.
3. Fast and efficient after-sales service are available.
HENAN DEXING MACHINERY EQUIPMENT CO., LTD was founded in 2010 year,engaged in exporting Wheel loaders, Excavators, Road rollers, Heavy duty trucks, Motor graders and Tractors,etc. In the business, our company insists getting reputation by " Quality" "Innovation" "Value" and "Responsiblity"
Closely cooperating with China Famous professional factories like XCMG, Foton SANY SDLG and so on, we have accumulated rich exprience in international trades with more than 30 countries, like Mexico, Chile, Brizil, Argentina Philippines Thailand ,Australia, USA, Canada, Sweden Uganda, Botswana etc.
Company's aim is to sell China qualified products to all the world with competitive price and excellent after-sale service. Welcome to China. Welcome to our company. Hope you can find the satisfied products here with us.
Sales Team Available
1. How about your team and service?
a.Team Attitude: Nice /Work: Professional/Communication: in time /Character:responsible
b. Service Quality: Guarantee /Price:Competitive / Delivery :on time /After-sales service: Fast and Efficient
2. What is the payment way.
We normally work on T/T term, sometimes we work on L/C term.
a. On T/T term, 30% down payment is required in advance, and 70% balance payment shall be settled before shipment.
b. On L/C term, a 100% irrevocable L/C at sight without “soft clauses” can be accepted. (For some particular countries like Algeria, Bengal etc.)
3. What is the delivery time?
If machine in the stock, we will arrange delivery within 7 days ;
If machine out of stock, we need 10-25 days to arrange production.
4. How to ship?
a. For 90% , we can ship by sea, to all main continents such as Africa, Middle east, Southeast Asia, South America, Oceania and Eurpe etc, eigher by container or RORO/Bulk shipment.
b. For neighborhood countries of China, such as Russia, Mongolia,Kazakhstan,Uzbekistan etc, we can do by road or railway.
c. For light spare parts in urgent demand, we can deliver it by international courier service, such as DHL,TNT,UPS, or Fedex etc.
