Xinneng new disc type wood bark branch biomass material crusher machine for briquette press
Company Information
Jinan Xinneng Machinery Equipment Co., Ltd. located in Jinan City, the capital of Shandong Province.
It has been specialized in biomass energy’s technology development and promotion since 2006, won lots of national technical patents in the field of biomass energy’s utilization.
With professional R&D team, excellent technical team, sales team and strong production capability, we have been devoting our self to the development and promotion of biomass energy’s utilization and all our products have got CE certificates.
Main Products:
Biomass briquette machine, Wood crusher, Vertical dryer, Biomass burner and Gasifier.
Product Description
PF4A crusher machine for briquette press adopts rotation type activity hopper,feeder system
adopts hydraulic power transmission, stepless speed change. Rotary hopper can be automatic lifting, and easy maintenance.
Knives adopts adjustable type, each tool can be adjusted angle then using four times, fixed knife can be using both side, greatly reduces the using cost.
Feed system adopts reliable hydraulic power transmission, feed and feeding system being stepless speed regulation comes true, then PF4A can be widely used in crushing kinds of materials, like straw, plastic, rubbishwaste, plancon, wood waste, etc,
Requirement of moisture is also lower, less than 60% will use well.
Outfeed system can be tow kind of wind force transportation or belt transportation, It can be customized depending on raw material and requirement of client.
Technical Parameters
disc crusher operation instruction | |
Total power |
60.5Kw |
Main power |
55Kw |
Spindle speed |
615r/min |
Quantity of knives |
128 |
Diameter of screen mesh |
20mm(can be customized) |
Capacity(Woods) |
4t/h |
Size after crushed |
below 300mm |
Volume of rotary hopper |
2.3m³ |
Rated speed of rotary hopper |
0-10 r/min |
Type of out feeding |
wind force transportation(can choose belt transportation) |
Weight of device |
4980Kg |
Size of device |
2800X2735X1964mm |
Talk with us. We will be happy to advise you.
Application
PF4A crusher machine for briquette press can be widely used in crushing kinds of materials,
like straw, plastic, rubbish waste, plancon, wood waste, etc.
Delivery Site
OUR SERVICES
Our services for crusher machine for briquette press
1. The warranty is 12 months.
2. We provide after-sale services through the email, fax or telephone and we will definitely response within 24 hours once we received the message or any information.
3. Our engineers could provide complete design plans based on your materials or any other equipments according to your data and information.
4. We also provide engineers to go to your factory and train your technicians.
5. OEM Services.
Patented and CE certificates
Patented and CE certificates for all our crusher machine for briquette press and other machines.
