Help CenterMR-L5 OEM Plastic Side Mounted Liquid Level Sensor Float Level Switch
Related Products
-
MR-L4 Side Mounted Liquid Level Sensor for Water TankUS$ 1.5 - 2.5MOQ: 10 Pieces -
MR-L4 OEM Side Mounted Liquid Level Switch Water Sensor M16US$ 1.5 - 2.5MOQ: 10 Pieces
-
MR-L3 Electric Water Level Switch Side Mouted Float Level SwitchUS$ 1.5 - 2.5MOQ: 10 Pieces
-
MR-L3 OEM 50w Plastic Float Switch Side Mounted Water Level SensorsUS$ 1.5 - 1.9MOQ: 10 Pieces
-
MR1078-SL Stainless Steel Easy Install Water Float SwitchUS$ 4.2 - 4.9MOQ: 10 Pieces
Float ball liquid level Sensor
1.long working life 2.stable performance 3.easy mounting 4.multi points control
Specifications
u Specifications
item |
technical parameters |
|
Max contact power |
10W |
50W |
Max switch voltage |
100VDC/100VAC |
350VDC/300VAC |
Min break down voltage |
150VDC |
600VDC |
Max switch current |
DC0.5A |
DC0.7A/AC0.5A |
Max carry current |
1.0A |
2.5A |
Max contacts resistance |
100mΩ |
100mΩ |
Min insulation resistance |
109Ω |
1010Ω |
Contact life |
107 |
|
Applicable environment temperature |
-10~+85℃/-40~+125℃ |
|
material |
PP/SUS304,SUS316(customization) |
|
Assemble screw |
M10*1,NPT1/8,NPT1/2(customization) |
|
Floating ball standard |
Ø24*24,Ø28*28(customization) |
|
Compression resistance of floating ball |
0.7Mpa,1.4MPa (customization) |
|
lead |
UL 1015 22AWG(customization) |
|
operating principle
Liquid level sensors mainly consists of magnetic Reed switch and floater . There is a magnetic material in the floater that will trigger the magnetic Reed switch as the level of the liquid tested moves up and down , and thus detecting the position of the liquid level.
characteristic
Liquid level sensors used imported components and is provided with characteristics such as compact size ,simple working principle, highly reliable and inexpensive.Floating balls with different materials and specifications are available for selection .Electrical parameters can be changed in accordance with client's requirement,and special specification can also be customized.
Application field
This product can be used in liquid level control for watering machine , water heater , solar energy ,air conditioning , moisturizing machine , bathroom utensil , vending machine ,oil tank , water tower and chemical industrial ,etc. It will bewidely applied in motor vehices ,industrial equipment , agricultural equipment and household electrical appliances in the Future.
Application
Water fountain,air cindition,humidifier,bathroom equipment,sale machine,oil tank and chemical liquid level control.It will be widely applied in motor vehicles,industrial equipment,agricultural equipment and household appliances in the future.
Package
Standard plastic bags and cartons, also we can provide customized design for all kinds package.
Production Line
Our factory management is in accordance with international 5S standards, strict requirements and supervision of the various production processes.
Latest Exhibitions
We attended the Electronica in Germany in Nov 2014, new products have won the praise of many buyers.
Owned Certifications
