1.Special designed 2.Low cost 3.Simple installation4.wide application
Introduction
flow sensor consists of magnetic core, rotating impeller, external casing and sensor.Flow through the sensor activates the magnetic core to trigger switch action, with signal output.
Features
imported components of the magnetic switch, sample working principles, and highly reliable, cheaper price.
Applications
it is used in the control of water circulation, water charging and discharging, water heating, water pump switch on and off of solenoid valve, or powering on and off of water discharging for electric water heater, solar energy water heater, air condition and other water systems.
Flow sensor
u Specifications
Withstand hydraulic pressure |
<0.35MPa |
||
Voltage rating |
5~24VDC |
||
Insulation res |
>100MΩ |
||
precision |
0.2~6L/MIN±10% |
2~30L/MIN±10% |
1~60L/MIN±10% |
Max output pulse voltage |
>4.7VDC(input voltage5VDC) |
||
Min output pulse voltage |
<0.5VDC(input voltage5VDC) |
||
Output pulse duty cycle |
50%±10 |
||
Junction way |
Red wire +,black wire-,white(yellow)wire output signal |
||
Package
Standard plastic bags and cartons, also we can provide customized design for all kinds package.
Production Line
Our factory management is in accordance with international 5S standards, strict requirements and supervision of the various production processes.
