BX215 advanced structure wood veneer cutting machine
Introduction of wood veneer cutting machine:
Drum wood chipper is the special chip working machine, widely used in particle board factory,high density fiberboard factory, stubble factory, biomass powder plant, wood factory etc. Industries, especially used in preparation before production.
There are two or three four fly blades fixed into the blade roller by pressure and special bolts. The feeding roller can float up in a certain range with the help hydraulic system according to the different chips thickness,The cutting down qualified material drop out though screen mesh and discharge from bottom,the large material will be cut inside again.
Hydraulic system: Supply oil to cylinder by hand oil pump,you can start the cover shell for replace blades conveniently.When maintain and repair you can uplift the feeding roller assembly for good conveniently adjust the fly blades,bottom blades gap and dismantle comb plate.
Technical Parameters:
Model |
BX215 |
BX216 |
BX218 |
BX2113 |
Feeding port size(mm) |
160*400 |
230*500 |
300*680 |
450*700 |
Fly blades quantity(pcs) |
2 |
2 |
2 |
2 |
Blades speed(r/min) |
592 |
590 |
650 |
500 |
Max diameter of raw materials(mm) |
160 |
230 |
300 |
450 |
Wood chips size(mm) |
30 |
30 |
30 |
38 |
Capacity(t/h) |
3-4 |
7-10 |
12-15 |
15-30 |
Main motor power(kw) |
45 |
55 |
110 |
200-250 |
Feed roller motor power(kw) |
2.2-3 |
3-4 |
4-5 |
7.5*2 |
Pump motor power(kw) |
1.5*1 |
1.5*1 |
1.5*1 |
3*1 |
Weight(kg) |
2990 |
4070 |
7000 |
11840 |
Dimensions(mm) |
1470*1550*970 |
1800*1900*1210 |
2200*2150*1500 |
3670*2517*2050 |
Conveyor motor power(kw) |
3 |
3 |
3 |
3 |
Features:
1. This machine with advanced design and structure, processing high quality wood chips.
2. It is consist of main machine, knife roller, knife blades, feeder, conveyor, hydraulic pressure system, etc. Machine body is welded by high strength steel plate forming the integrated support base.
3. Knife roller with 2-4 knifes which can be adjusted up and down based on the thickness of wood chips required. Qualified chips come down through the screener and outlet, but big block will return to crushing room for second processing.
4. The hydraulic system is consist of oil pump, hydro cylinder, which can start up the cover for blades changes and maintenance.
5. The machine is suitable for processing of wood waste and other waste materials such as density board, straw etc.
Working principle of BX series wood veneer cutting machine:
According to the thickness of the different raw material, top feeding roll can move up and down with the help of hydraulic system. The qualified final product will be discharged from the sieve and then out of the base, the bigger pieces will be crushed in the machine again.
Photos for BX215 wood veneer cutting machine:
BX218 wood veneer cutting machine
BX2113 wood veneer cutting machine
Different view of BX series wood veneer cutting machine
Machine without painting:
Some spare parts:
Wood chip made by our wood drum chipper:
1. Free tool box and free easy damage parts
2. Warranty: warranty time is 12 months after the goods delivery your port.
3. Color: according to your requirement
4. Logo: can stick your logos free if you need
5. Delivery time: 25 working days after the down payment
6. Payment: The payment term is T/T (30% deposit in advance, 70%T/T as balance before shipment)
7. Spare parts are supplied too for your machine if you need
8. technical service offered whenever you are in need
Our service:
1) Pre-sale Service:
Design suitable product, offer reasonable consultation and referring documents.
2) After-sale Service:On the spot guidance for installation by our enginee, and the buyer is responsible for the Expense. We have perfect after-sales service system and team with professional advice and guidance for whole using life.
3) All order will be supplied within the stipulated period.
Henan Guangda is a professional manufacturer and supplier of farm machinery, has been engaging in the international trading for 14 years. Agricultural and forest machinery, such as wood crusher, drum/disc wood chipper, twin shaft shredder, compound crusher chipper in-one-machine, wood pellet mill, animal feed pellet produciton line, hammer mill,dryer, etc. are our main products, one-stop service is our main feature. Products are widely exported to over 50 countries all over North America, Europe, Africa, South America and Southeast Asia. Featuring high quality standards, rigorous management measures and advanced technology, we have built up very fine reputation among both domestic and overseas customers.
Welcome to contact us:
Good quality, mature technology, competitive price and good after-sales service.
If you want a more competitive price and more information about our wood veneer cutting machine, welcome to contact us, Thanks.
