mini excavator towable backhoe for farm tractor
thumb optial
Backhoe loder
different bucket size ailable
3 point linkage backhoe attachment
Features:
1. Italian imported valve element, better performance
2. Arm swing can reach 180°, LW series is 140°
3. Box structure arm, light weight and high intensity
4. Camber beam design with digger digging depth and more powerful, small volume, easy for operating and transporting
5. Equipped with safety stand, minor vibration while working, high stability
Photo of the Backhoe:
Technical Data:
GX Backhoe | ||||
specifications |
GX610 |
GX710 |
GX910 |
|
A |
Transport Height (with boom fully retracted) |
63" |
79" |
92" |
Loading Height(bucket at 60 rotation) |
62" |
80" |
89" |
|
B |
Ground Clearance |
10.5" |
10.5" |
10.5" |
C |
Transport length |
68" |
80" |
81" |
D |
Digging Depth(2ft,flat bottom) |
6'1" |
7'1" |
9'1" |
E |
Overall Operating Height(fully raised) |
92" |
119" |
135" |
F |
Reach from Swing post |
98" |
120" |
138" |
G |
Bucket Rotation |
180° |
180° |
180° |
Swing Arc |
180° |
180° |
180° |
|
Stabilizer Width(speed) |
74" |
89" |
89" |
|
Stabilizer Width(Transport) |
40" |
42.5" |
42.5" |
|
Operating Pressure |
1800psi |
2250psi |
2250psi |
|
Hydraulic Volume Requirements |
5-7 gpm |
5-7 gpm |
7-9 gpm |
|
Recommended Tractor HP |
15-25HP |
22-65 HP |
45-100 HP |
|
Bucket Sizes Available |
10,12,16,18 |
10,12,,14,16,18,20,22 |
9,12,16,18,20,24 |
|
|
3-Point Hitch
|
Cat I(PT2020) (RT3012) |
Cat I(PT2020) (RT3016) CatII(PT2022)(RT3016) |
Cat I(PT2020) (RT3016) Cat II(PT2022)(RT3016) |
|
Packing & Shipping :
|
|
|
|
| Pre-sales | Service online for 24hours to wait for your inquiry |
| Sale tracking |
Provide specification, photos, and delivery cost for you. Answer your questions and solve your problems at any time. |
| After-sale service |
12months warranty for the machine without wearing parts. We will deliver damaged parts (except wearing parts) for free based on quality problem within warranty period. Wearing parts are also sold to match your machine if needed. |
| After-sale service process |
If some parts damaged, please take photos and shoot video firstly, please send us in time. We will pass your problems to our after-sale department to deal with. Solution will be provided for you as soon as possible. |
Henan Guangda is a professional manufacturer and supplier of farm machinery, has been engaging in the international trading for 14 years. 12-180hp wheel tractor, agricultural implements and forest machinery are our main production, one-stop service is our main feature. Products are widely exported to North America, Europe, Africa, South America and Southeast Asia. Featuring high quality standards, rigorous management measures and advanced technology, we have built up very fine reputation among both domestic and overseas customers.
