1.YYW-300B universal joint drive balancing machine technical parameters sheet :
Specifications |
Parameters |
Mass Scope of Workpiece (kg) |
300 |
Max Diameter of Workpiece (mm) |
1200 |
Distance Between Two Support Bearings (mm) |
Min:60 |
Journal Diameter Scope of Workpiece (mm) |
20~180 |
Max Distance between Driving Flange and Right Bearing Support (mm) |
2100 |
Rotation Speed of the Main Axis (r/min) |
315/630/570/1140 |
Motor Power (kw) |
5.5 |
Torque of Universal Joint Shaft (N·m) |
60 |
Min Achievable Residual Unbalance Amount (emar) |
1g· mm/kg |
2. YYW-300B universal joint drive balancing machine Notes :
(1)term of payment is :
By T/T :In advance 40% ,the other 60% before the machine delivery
(2)Delivery time :30days after the seller received the advance payment
(3)Package :standard export wooden box
(4)Warranty :one year
3.YYW-300B univeral joint drive dynamic balancer dimension
1).YYW-300B blancing machine size
L*W*H=3.2*0.81*1.32=3.4215CBM
Net Weight :1350kg Gross weight :1400kg
2).JP-380 digital controller size
L*W*H=0.68*0.67*1.73=0.7882CBM
Net Weight :70kg Gross weight :100kg
3).Total is :4.2097CBM Gross weight :1500kg
4. YYW-300B univeral joint drive dynamic balancer Production Description
• Special designed brackets can effectively transmit mechanical force
• The durable and reliable sensor possesses high sensitivity
• The permanent calibration brings high accuracy
• Driven by universal coupling,transmit the power steadily
• Applicable to rotors which can't be driven by belt or need large power
• Advanced electrical measuring system and friendly man-machine interface
YYW-300B univeral joint drive dynamic balancer Range of Application
This balancing machine is mainly used in checking the balance of rotatable bodies such as motors,
spindles of machine tools,blower,clinopodiums,centrifuges,pump impeller.drying cylinder.ceramic
machinery,rollers,rubber sticks,etc.. Driven by universal joints, and it can offer us a variety of rotation
speed,with features of high precision,easy to be operated and high efficiency,etc..
