MDC-025 Capsule Slip Ring /Current Collector
US$ 10 - 30
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
moda
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
MDC22-18 Capsule Slip Ring /Rotary JointUS$ 5 - 20MOQ: 1 Piece -
MDC22-6 Capsule Slip Ring /Rotary Joint/Collecteur TournantUS$ 7 - 8MOQ: 1 Piece
-
3 Wries 15A Wind Generator Slip RingUS$ 10 - 12MOQ: 1 Piece
-
MDC022-6A Capsule Slip RingUS$ 10 - 14MOQ: 1 Piece
-
MDC018-6 Capsule Slip RingUS$ 8 - 17MOQ: 1 Piece
Place of Origin
Zhejiang, China
Brand Name
moda
| MDC025 Capsule Slip Ring : | ||||||
| Mastering the key technique of design and manufacture,holding independence the intellectual property | ||||||
| Suffice the un-limit revolving video and the digital signals transmission of 360 degree completely | ||||||
| The integrated produce standard may meet the demand of client | ||||||
| Longstanding using life | ||||||
| Can be customised for Customer need the produce | ||||||
| Electrical Data: | ||||||
| Voltage: | 240VDC-240VAC | |||||
| Continous Curent(amps): | 2A/ring | |||||
| Lead size: | AWG28 ,AWG26:2A,AWG22:6A,AWG16:10A,Colour coded,FPE insulated lead wires | |||||
| Standard lead lenghts: | 250mm(other lenghts on request) | |||||
| High pot: | 500VAC60Hz | |||||
| Insulation Resistance: | 200MΩ/500VDC | |||||
| Dynamic contact Resistance | 0.01Ω | |||||
| Mechanical data: | ||||||
| Operate Speed: | 250rpm | |||||
| Temperature range: | -20-80 | |||||
| Contact material surface: | Gold-gold | |||||
| The stainless steel bearing: | The little ball double density seals bearing | |||||
| Description: | ||||||
| The slip ring can be used in any electro-mechanical system that requires unrestrained,continuous rotation while transmitting power and / or date from stationary to a rotaing structure.The slip ring is also called a rotary electrical interface,commutator,collector,swivel or an electrical rotary joint, The brush adopt noble metal alloy material,conducting ring using a 90°V-groove ring. It adopt multilayer noble metal alloy for plating disposee,Color-coded lead wires areused on both the stator and rotor for simplified electrical connections. | ||||||
| Application: | ||||||
| CCTV pan/tilt cammeras and pedestals | ||||||
| Robots and downhole inspection equipment | ||||||
| Test and measuring equipment | ||||||
| Manufactruing and process control equipment | ||||||
| Computer peripherals | ||||||
| Display equipment Medical equipment | ||||||
