Application
1.MT-200 Vertical round bottle non-dry tape marking machine, in order to achieve rationalization of production target and design.
2.Labeling process automation, simple operation, the production speed is quick, labeling position, beautiful, neat, For pharmaceutical, chemical and foodstuff trades etc circular vessels labeling.
Working principle and structural features
1.Will different packing objects into labeling machine belt conveyor, by driving a bottle into the bottle conveying institutions, continuous motion by depending on fiber detected after bottle, photoelectric signal transmission to PLC, by PLC output signal processing will lose to the stepping motor, the standard of stepping motor, through the rolling institutions will stick son, tag labeling of objects by labeling machine conveyor belt into the next procedure or containers.
2.Host adopts stepping motor driver, sets of (Taiwan) PLC control system, sets of (Taiwan) touch people interface, keyence fiber (Japan) device etc imported components, gathers numerous leading technology, make it become the industry has the advantage of technology products.
3.Microcomputer automatic control, interface screen friendly human-machine interface, ingenious mechanical structure, make the operation simple and powerful function, Can realize tag number, counting, set print control, labeling, lack of control, marking, colorless such abnormalities automatic detection and alarm functions, Random capacity and the quantity management label, Adjust tightness labels, The length and tags, Host height and adjust position before, Optional ribbon typewriter one, Labeling and tag with reaction degree detection.
4.The machine adopts high-quality T6 aluminum and stainless steel SUS304, well made, in conformity with the requirements of GMP.
main data
Driver stepping motor/servo motor
Operation right or left
Poster speed 0-200 PCS/min
A bottle 20 - diameter 100mm
Height 25-350mm bottle
Label size wide 10-150mm long 15-200mm
Labeling precision + 1mm (depending on the bottle degree, perpendicular round)
Maximum diameter volume label 300mm
Coil diameter 75mm label
Weight 200kg
Power supply AC110V / 220V / 500W 60HZ
This 2000X1300X1500 size
Printing device HP 260Q -(optional)
Packaging Sample
All our package are standard fumigated wooden box, we need around 5 working days to finish the machine and ready to deliver. If want extra spare parts pls notify when place order.
Shipping:
Machine usually transport by sea,we also can transport it by air and railway.
Delivery time: Within 15 workdays after receipt of the pre-payment.
Quality guarantee terms:
Quality guarantee is one year. Spare parts we supply at factory cost lifetime.
We will be responsible for any broken which are caused by machine-self and quality problem, other situations which are caused by wrong operation, man-made problems etc will be in buyer’s response, and we will help to solve by video asap, if big problem we will send engineer to working site within 1 week.
