Automatic Wheat Bagging Machine With Prices for Sale

BZJ-50 Bagging machine

1 1. Brief Introduction:
BZJ-50 quantitative bagging machine is composed of main machine(Weighing filling machine), conveyor, Bag-sewing machine and electronic computer control.
The main body is adopt strap fast, middle, slow three speed to control strap feeding, confirm big capacity, high weighting, high accuracy. It has advanced digital frequency technique, sampling treating technical, anti-jamming technique, and realize error automatic compensator and amend.
It is widely used in bagging wood/feed pellets, corn, wheat, beans and other kinds of grains.

2. Main machine control:
1). PLC control instrument display.
2). Main machine adopts Screw rotary filling controlled by faster and slower frequency transformer.
3). It has the automatic storage management of shift/day/cumulative production information.
4). Technical data:

Model: BZJ-50
Weighting capacity: 2-3bag/min
Weighting scope: 25-50Kg/bag
Weighing error: ±0.3%
Control type: PLC control
Power supply: AC220V/60Hz, 3 phase
Main power: 1.1kw
Air supply:  Instrument Air without oil and dust
Pressure: 0.4-0.5Mpa
Air consumption: 0.4Nm3/min

3. Equipment operation conditions:
Running time: 8000 hours/year
Environmental temperature: 10—40℃

4. Other
Air source: buyer needs to supply air source by self.
Air pressure: 0.4-0.65Mpa, power: 2.0kw.

5. Dimension:
L×W×H: 2.3×1.1×2.6m .

More pictures:

Packaging:

All our package are standard fumigated wooden box, we need around 5 working days to finish the machine and ready to deliver. If want extra spare parts pls notify when place order.

Shipping:

Machine usually transport by sea,we also can transport it by air and railway.

Delivery time: Within 15 workdays after receipt of the pre-payment.

Quality guarantee terms:

Quality guarantee is one year. Spare parts we supply at factory cost lifetime.

 We will be responsible for any broken which are caused by machine-self and quality problem, other situations which are caused by wrong operation, man-made problems etc will be in buyer’s response, and we will help to solve by video asap, if big problem we will send engineer to working site within 1 week.
