Specifications
1.Mode1: VCP-40002.Packing efficiency: 20-40 loads per hour
3.Turntable loading(max): 2000kg
4.PLC control: Yes
5.CE: Yes
VCP-4000 Stretch Film Wrapping Machine
Introduction:
1. Stretch wrapping machines are used to wrap stretch film around a loaded pellet.
2. Film provides extra support while the products are being transported & storaged to protect them from trip, spill or from being damaged.
3. Stretch pallet wrapper is widely used in chemical indusry, electronic industry, building materials, home appliances, paper making, foodstuff & drink etc.
4. Additionally, wrapped loads can easily be separated and identified.
Main characteristic:
Up-down frame Heavy duty double-chain carriage lift, calm and safety
Control System: PLC control
Photo-eye auto-height sensing pallet height
Separate top, bottom & up-down Wrap Counter options
Over-wrap time is up to create an over-wrap
Reinforce wrap times is set to better secure 2 loads placed on top of each other
Film Tension Control adjustment on the panel
Separate start, pause and emergency stop buttons
Power indicator
Manual carriage up/down
Variable Turntable Speed
Carriage up/down speed control
Manual/automatic exchangeable
Film carriage
Powered pre-stretch system up to 250% to min film consumption
Carriage door opens for effortless roll change and thread film
Film delivery variable speed by separate DC Drive Motor
Electronic film tension control adjustment on panel
Film dancer-bar with variable speed output
Main Data for VCP-4000
Model |
VCP-4000 |
VCP-4000D with Coping |
Turntable Diameter |
1500 mm |
|
Packing Efficiency |
20-40 loads/hour |
|
Turntable Loading(max) |
2000 Kg |
|
Control System |
PLC Controller |
|
Machine Weight |
740 kg |
760 kg |
Packing Height |
1800 mm |
2000 mm |
Machine Dimension |
2800×1600×3200 mm |
2800×1600×3200 mm |
Power/Voltage |
1300w, 380/220v/50HZ |
1300w, 220/380V/50HZ |
Picture for VCP-4000
Packaging:
Package: In wooden Box
Shipping:
By sea.
Quality guarantee terms:
Quality guarantee is one year. Spare parts we supply at factory cost lifetime.
We will be responsible for any broken which are caused by machine-self and quality problem, other situations which are caused by wrong operation, man-made problems etc will be in buyer’s response, and we will help to solve by video asap, if big problem we will send engineer to working site within 1 week.
