Help Center100HP XCMG Mini Motor Grader GR100 Chinese Motor Grader Price for Sale
Related Products
-
XCMG Road Roller XD 81E Made in China Low Emission High Quality for SaleUS$ 10,000 - 50,000MOQ: 1 Set -
XCMG Brand 26Ton XS263 Hydraulic Road RollerUS$ 107,000 - 121,000MOQ: 1 Set
-
XCMG Brand 18Ton XS183 Hydraulic Road RollerUS$ 90,000 - 94,000MOQ: 1 Set
-
XCMG Brand 16Ton XS163 Hydraulic Road RollerUS$ 67,000 - 72,000MOQ: 1 Set
-
XCMG Brand 20Ton XS203 Hydraulic Road RollerUS$ 94,000 - 97,000MOQ: 1 Set
XCMG MINI Grader GR100
♦Company Information♦
Advantages-
- 14 years experiences on tractor manufacturing and exporting.
- We have strong technical support and production capacity.
- Our factory close to the sea port, transportation is very convenient.
- Professional sales team, offering personalized and dedicated services.
- Unique designed strong container fixed method can protect the tractor.
- Top quality tractor with ISO9001 Certificate.
Basic specification | |
Engine model |
4BT3.9 |
Rated power/speed |
75/2400kw/rpm |
Dimension(L*W*H) |
6880*2375*3150mm |
Operating weight(Standard) |
7000kg |
Performance specification | |
Travelling speed forward |
5/10/20/39km/h |
Travelling speed reverse |
8/25km/h |
Tractive force(f=0.75) |
41.6KN |
Max. grade ability |
20% |
Tire inflation pressure |
350KPa |
Working hydraulic pressure |
16MPa |
Transmission pressure |
1.3-1.8MPa |
Operating specification | |
Max. steering angle of front wheels |
±50° |
Max. lean angle of front wheels |
17° |
Max. oscillation angle of front axle |
±15° |
Max. oscillation angle of balance box |
|
Frame articulation angle |
±27° |
Min. turning radius using articulation |
5.9m |
Blade | |
Maximum lift above ground |
300mm |
Maximum depth of cutting |
350mm |
Maximum blade position angle |
45° |
Blade cutting angle |
28°-70° |
Circle reversing rotation |
120° |
Moldboard width*height |
3048*500mm |
