SHANTUI Brand SG18-3 Motor Grader
SG18-3 Motor Grader Basic Specification
| Model | SG18-3 Motor Grader |
| Engine | 132Kw Kummins |
| Operatinig Weight | 16200kgs |
| Traclive force(Kn) | 85.5 |
| Max Speed(Km/h) | 0–39.7 |
| Dimension(L*W*H) | 8960*2600*3400 |
Technical Specification of SG18-3 Motor Grader
ITEM |
SG18-3 |
|
Engine |
Kummins 6BTAA5.9-C180 |
|
Rated power (kW/rpm) |
132/2200 |
|
Travel speed (km/h) |
Forward 1 |
0–5.4 |
Forward 2 |
0–9.3 |
|
Forward 3 |
0–12.2 |
|
Forward 4 |
0–20.7 |
|
Forward 5 |
0–25.6 |
|
Forward 6 |
0–39.7 |
|
Reverse 1 |
0–5.4 |
|
Reverse 2 |
0-12.2 |
|
Reverse 3 |
0–25.6 |
|
Dimensions (L*W*H) (mm) |
8960*2600*3400 |
|
Minimum turning radius (mm) |
7800 |
|
Wheel base (mm) |
2155 |
|
Gradeability (°) |
20 |
|
Maximum traction (KN) |
85.5 |
|
Maximum cutting depth (mm) |
500 |
|
Operating weight (kg) |
16200 |
|
Blade width (mm) |
3360/3965 |
|
Blade height (mm) |
635 |
|
Blade rotational angle (°) |
360 |
|
Ma×imum lifting height (mm) |
410 |
|
Blade cutting angle adjustment Range (°) |
44–91 |
|
Min. ground clearance (mm) |
430 |
|
Working hydraulic system pressure (MPa) |
16 |
|
Brake System Pressure (MPa) |
10 |
|
SHANTUI SG18-3 Motor Grader Features
After sales Service
Warranty: We grants our clients a 12 month or 2000 hours warranty for any machines purchased from us. During the warranty period, in case the defect of material or workmanship has occurred with spare parts in normal operation, the defective parts will be repaired or replaced free of charges at our discretion.
Spare parts: We is dedicated to provide our clients with genuine spare parts with the highest quality, exact fitness and appropriate function. With our global distributor network, you are guaranteed with fast deliveries and service, wherever you are. Please submit your spare parts requires to us and list products name, model equipment serial number, description of required parts. We guarantee that your requires will be handled quickly and appropriately.
Installation & Maintenance: We is able to provide you with the overall installation of complicated machinery and equipment, allowing you to start the normal operation of generators set and engine immediately. After installation, we will make inspection of the whole machine, operate equipment and provide you with testing date reports of installation and operation.
Training: We offer perfect facilities and comfortable environment and can provide training service to different users. The training sessions include product training, operating training, maintenance know-how, technical know-how training, standards, laws and regulation training and other trainings, all of which are tailored to fulfill your individual needs. Training programs can be conducted in our factory field, or at the clients side.
Technical Advice: We can also help clients coordinate with trained service personnel to provide you detailer and extensive knowledge about your specific machine, with our technical advices, you machine service life can be significantly prolonged and sustained with high capacity.
