New farm tractor, 50/55/60HP 4WD tractor with ROPS, sunshade with front end loader

FOB Price

USD $2,100 - $8,500 / Unit

1 Unit(Min.Order)

Product Details

1.farm tractor,4WD tractor
2.8F+8R
3.rops,sunshade
4.Dual stage cluth,Shuttle gear
5.plough,harrow,loader,backhoe etc

Introduction of High quality Farm tractor,HS554, 55HP, 4WD with rops, sunshade

Advantages and Characteristics of 50/55/60 series tractor:

1. Equipped with famous brand engine, with good performance, low fuel consumption and high economic efficiency.

2. Streamlined appearance with novel design.

3. 6 or 8 spline PTO( Power Take Off).

4. Rotation speed of PTO: 540/1000r/min.

5. Can be equipped with ROPS, canopy, cabin, front/rear ballast, loader, and so on;

6. Tire size: front tire 8.3-20, rear tire 13.6-28.

7.Can match implements such as Front end loader, Backhoe, Plough, Harrow, Trailer, snow blower, and so on.

Main Technical Data of Farm Tractor HS554

Item				Unit	Design value
Overall unit	Brand			/	Haishan
	Model			/	HS554
	Type			/	4*4 4WD
	Overall dimensions WDH			mm	3850×1650×2325
	Wheelbase			mm	2040
	Tire tread (front/rear wheel) adjustment way			/	Non-tunable/overturn plate
	Minimum ground clearance (position from the site)			mm	325 (Steering tie rod)
	Min service mass			kg	2280
	Front / rear axle weight			kg	1030/1250
	Weight distribution (front/rear, max)			kg	150/200
	Gear number (forward/reverse/crawling)			/	8/8/0
	Theoretical velocity of each gear	Low 1	Low reverse1	km/h	2.57	2.30
		Low 2	Low reverse2		3.73	3.33
		Low 3	Low reverse3		5.09	4.54
		Low 4	Low reverse4		8.14	7.27
		High 1	High reverse1		13.00	11.61
		High 2	High reverse2		16.62	14.84
		High 3	High reverse3		25.88	23.11
		High 4	High reverse4		36.32	32.43
	Connection way of engine and clutch			/	Direct connection
	Start-up way			/	Electrical start-up
	The output power of PTO shaft			KW	36.5
	Maximum traction force			KN	9.98
Cab or safety frame	Model			/	/
	Type			/	/
Engine	Brand			/	YTO
