JM Agricultural Tractor Fit for TZ04D Timer Grapple, Front End Loader

Name: JM Agricultural Tractor Fit for TZ04D Timer Grapple, Front End Loader
Brand: TS Brand
SKU: 138998269

US$ 1,850 - 2,550 MOQ: 1 Unit

Key Specifications

Type:

Other, Front loader

Use:

Tractors

Place of Origin:

Shandong, China

Gooler International Group Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao / Shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Type Other, Front loader

Use Tractors

Place of Origin Shandong, China

Brand Name TS Brand

Model Number TZ04D

Specifications

1. Quick link
2. Timer grapple
3. Single hand control
4. Fit tractor model 40-55HP

tractor fit for TZ04D Timer Grapple, front end loader

Model	LW-6	LW-7	LW-8	LW-9
Tractor model	254/304/324/354	404/454/504/554/604/654	704/754/804/854/904	1204/1254
L1 (mm)	495	495	500	505
L2(pin of the boom distance)(mm)	517	540	632	650
φ1(diameter of up hang pin hole) (mm)	20	20	26	26
φ2(diameter of down hang pin hole)(mm)	20	23	29	32
A Max digging depth(mm)	1700	2100	2600	3100
B dump height (mm)	1700	2300	2500	2700
C Max digging height(mm)	2700	3300	3400	3500
E height of arm pin to ground(mm)	430	430	450	450
F Max digging depth in level base (mm)	1600	2000	2500	3000
Dump angle (°)	42°	42°	42°	42°
Bucket width (mm)	340	380	420	460
Rated lift capacity (m3)	0.03 m³	0.048 m³	0.06 m³	0.072 m³
