CP300 China Top Quality Compact Wheel Loader With ce and ROPS Cabin Sale in Canada

CP300 China Top Quality Compact Wheel Loader With ce and ROPS Cabin Sale in Canada thumbnail-1
CP300 China Top Quality Compact Wheel Loader With ce and ROPS Cabin Sale in Canada thumbnail-2
CP300 China Top Quality Compact Wheel Loader With ce and ROPS Cabin Sale in Canada thumbnail-3
CP300 China Top Quality Compact Wheel Loader With ce and ROPS Cabin Sale in Canada thumbnail-4
CP300 China Top Quality Compact Wheel Loader With ce and ROPS Cabin Sale in Canada thumbnail-5
CP300 China Top Quality Compact Wheel Loader With ce and ROPS Cabin Sale in Canada thumbnail-6
CP300 China Top Quality Compact Wheel Loader With ce and ROPS Cabin Sale in Canada photo-1
CP300 China Top Quality Compact Wheel Loader With ce and ROPS Cabin Sale in Canada photo-2
CP300 China Top Quality Compact Wheel Loader With ce and ROPS Cabin Sale in Canada photo-3
CP300 China Top Quality Compact Wheel Loader With ce and ROPS Cabin Sale in Canada photo-4
CP300 China Top Quality Compact Wheel Loader With ce and ROPS Cabin Sale in Canada photo-5
CP300 China Top Quality Compact Wheel Loader With ce and ROPS Cabin Sale in Canada photo-6
US$ 11,000 - 16,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
CP
Model Number:
CP300
Contact Supplier Request Quote Chat Now
Weifang CP Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Brand Name CP
Model Number CP300
Place of Origin Shandong, China
Type Front Loader
Moving Type Wheel Loader
Dimension(Long * Breadth * High) 6170x2040x2695mm
Rated Load 3000kg
Certification CE ISO ROPS
Warranty 12months
After-sales Service Provided No overseas service provided
Product Description

Product Application

CP300 (H580) China top quality compact wheel loader for sale with ROPS Cabin and Certificate

Our new type compact wheel loader from German technology,this is high-end wheel loader,high quality cabin,Z-bar Linkage,engine hood,all the parts are in the lead in wheel loaders' field China,

SPECIFICATIONS FOR CP300 WHEEL LOADER









           Performance
Model
CP300 (H580)
Rated loading
3000Kg
Rated bucket capacity
1.2m3
Operation weight
5570Kg
Overall dimension (LxWxH)
6170x2040x2695mm
Wheelbase(mm)
2475mm
Tread(mm)
1600mm
Base to the ground(mm)
520mm
Max. speed
35km/h
Min. turning radius
4510mm
Max. tractive force
≥56KN
Max. breakout force
≥45.4KN
Max. grade ability
30°
Max. dump height
3300mm
Dump distance
930mm




                Engine
Model
YN38GBZ (YUNEI brand)
Type
Vertical, in-line, water cooled, 4-cylinder, turbo type
Rated power
76KW / 103hp
Rated speed(r/min)
2400rpm
Max. torque
285N.m
Displacment
3.76L

  Transmission system
Torque converter
ZL280
Gearbox mode
Contershaft, power-shift
Gear shift
2 forward (1 high speed, 1 low speed), 1 reverse

            Drive axle
Main reducing spiral
Circular Arc Bevel gear, single stage
Decelerating mode
Single stage planetary type



   Hydraulic system
System working pressure
16MPa
Boom lifting time
4.8s±0.2s
Total time
9.2s±0.5s
Fuel tank capacity
80L
Function of leveling automatically
Yes
      Brake system
Service brake
Hydraulic disc brake on 4 wheels
Parking brake
Flexible shaft operated external drum

            Tyre
Tyre size
16/70-20
Front tyre pressure
0.22Mpa
Rear tyre pressure
0.18Mpa

Main Features

1) Reliable and Robust

2) Convenient Operation

3) Giving great vision at all directions

4) With ROPS and FOPS

5) Technology from German

Detailed Images

Machine Parts

Name: Engine

Brand: Yunnei

Original: China

Famous brand in China,

Main Features

Name: Quick Hitch
Brand: CP
Original: China
New Type (German technology)

Machine Parts

Name: Hinge joint
Brand:  CP
Original: China
New Type (German technology)

Main Features

Name: Engine Hood
Brand: CP
Original: China
New Type (German technology)

Our Service

Parts & Service

*To ensure exceptional customer satisfaction, we maintain a large inventory of parts. Our highly trained, experienced service technicians are available to dealers to help keep up with proper maintenance and warranty service procedures.

After-Sales Service

* We have one year warranty,During Warranty, if there is any part broken because of quality problem(except easy-damaged parts), send us detailed pictures, then we will send good/ new parts for your replacements.

Packing & Delivery
Packaging
Size
6170 (L) * 2040 (W) * 2695 (D)
Weight
5570Kg



Packaging Details
2 units in a 40'HQ
The normal package is 10mm wire and Triangle wood or steel.
Packaging
Size
6170 (L) * 2040 (W) * 2695 (D)
Weight
5570Kg



Packaging Details
The normal package is 10mm wire and Triangle wood or steel. If container is too tigher,we will use pe film for packing or pack it according to customers special request.
