50hp 504 4WD chinese farm tractor 50 hp
1. 4102 engine
2. 45hp farm tractor
3. 4x4 wheel drive
4.different farming implements
Specification
Model | 504 |
Type | 4WD Wheeled Type |
Length(to the front ballast) | 3835mm |
Width | 1620mm |
Height (to the exhaust vent) | 2135mm |
Front Wheel Tread | 1280mm |
Rear Wheel Tread | 1300 Fixed or 1200-1500 Adjusted |
Axle Base | 2030mm |
Min. Ground Clearance | 325mm |
Structure weight | 1734kgs |
Front ballast weight | 168kgs |
Rear ballast weight | 300kgs |
Rated traction force | 1150kgs |
Engine Model | 4102 |
Engine Type | 4-Cylinder |
Cooler type | Water |
Stroke | 4 Stroke |
Rated Power | 40km |
Rated Speed | 2400r/min |
Fuel | Diesel |
Front Wheel Tyre | 8.3-20 |
Rear Wheel Tyre | 12.4-28 |
Clutch | Dual-stage clutch |
Steering | Power steering |
Transmission Type | 8+4 or 8+8 with shuttle gearshift or (8+4)×2 with creeper shift |
Suspension Type | 3-point links |
Air braking | yes |
Cabin & heater | with |
504 Farm Tractor
Different farming implements optional
