ZL-10F Model Mini Compact Wheel Loader for Sale With CE Certificate

Name: ZL-10F Model Mini Compact Wheel Loader for Sale With CE Certificate
Brand: Forlay
SKU: 138977893
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Brand Name:

Forlay

Model Number:

ZL-10B

Yancheng Forlay Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name Forlay

Model Number ZL-10B

Place of Origin Jiangsu, China

Type Front Loader

Moving Type Wheel Loader

Dimension(Long * Breadth * High) 4750*1500*2530

Rated Load 1000KGS

Certification CE

Warranty 2 Years

After-sales Service Provided Overseas service center available

Specifications

*Rated Loading weight: 1000kg
*Rated Bucket Capacity: 0.5m3
*Operating weight: 2700KG
*Min. Turning Radius: 4700mm

THE TECHNICAL PARAMETERS OF ZL10F CE CERTIFICATE MINI WHEEL LOADER
Model	ZL10F	Driving mode	Four-wheel drive
Rated loading weight	1000kg	Operating weight	3300kg
Rated bucket capacity	0.5CBM	Dimension(L×W×H)	4750 ×1650×2720mm
Bucket width	1600mm	Engine model	CHANGCHAI 490
Track base	1400mm	Engine type	In-line arrangement, water cooled, four-cycle diesel Engine
Wheel base	1580mm	Engine starting mode	Electric
Min. swerve diameter	3890mm	Rated speeds	2200rpm
Min. ground clearance	230mm	rated power	29kw
Dump height fully raised	2200mm	Brake mode	Four-wheel hydraulic spread-shoed brake
Reach fully raised	850mm	Color	According to the requirements of customers
Lifting time	4s	Tyre	8.25-16
Hydraulic cycle time	9s	Packing details	Nude package, 1Unit/20's GP with disassembled cabin, 3Units/40's HQ
Max. tilt angle	300	Delivery time	20 days after confirm the order, received the advance
Max. bucket breakout force, lift cylinder	26KN	Supply ability	100 units per month
