Home > Products > WATER PUMP > 6.5HP Diesel Engine Driven Water Pump(Max.Flow Rate 14m3/h)
6.5HP Diesel Engine Driven Water Pump(Max.Flow Rate 14m3/h)
- 5000 Set / Sets per Month
- Shanghai China
- T/T
- MONO progressive block for prefabried concrete houses
- MONO progressive block for concrete pump spare parts
- MONO progressive block for ready mix concrete trucks
- MONO progressive block for concrete statue molds
- MONO progressive block for concrete columns mold
- MONO progressive block for gearbox for concrete mixer
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | LDP | Model Number: | TT40D TT50D |
Theory: | Centrifugal Pump | Structure: | Single-stage Pump | Usage: | Water |
Power: | Other, Diesel Engine | Standard or Nonstandard: | Standard | Fuel: | Diesel |
Pressure: | High Pressure | Application: | Other, agriculture irrigation, pump for house, sprinkler pumps, fire pump |
Product Description
Specifications
1) Maximum capacity of 51UKGallons per minute2) High output,High pressure.
3) Heavy-duty full frame protection.
Model | TT40D | TT50D |
Outlet Size(mm) | 40 | 50 |
Inlet Size(mm) | 50 | 50 |
Displacement(m3/h) | 14 | 20 |
Lift(m) | 55 | 60 |
Suction(m) | 7 | |
Engine Model | D178 | |
Type | Single-cylinder,Vertical,4-Stroke,Air-cooled,Direct-injection,Diesel | |
Displacement(cc) | 296 | |
Bore(mm) | 78 | |
Stroke(mm) | 62 | |
Speed(rpm) | 3600 | |
Continuous Output(hp) | 6.5 | |
Max.Output(hp) | 7.2 | |
Fuel Consumption(g/hp.h) | 215 | |
Power Take Off | Crankshaft or Camshaft(Camshaft Pto RPM is 1/2 of Crankshaft) | |
Output Direction of PTO | Counter-colokwise | |
Starting System | Recoil or Recoil/electric | |
Cooling System | Forced Air | |
Governor System | Centrigugal Weight System | |
Fuel | Diesel | |
Fuel Tank Capacity(L) | 3.5 | |
Lub.Oil Capacity(L) | 1.1 | |
Continous Woking Time(h) | 2.5 | |
Dimensions(mm) | 485*450*550 | 490*455*550 |
N.W/g.w(kg) | 62/63 | 63/64 |
