Home > Industrial Equipment & Components > Pump & Vacuum Equipment > Water Pump > 5.5HP~11HP Gasoline Water Pump

5.5HP~11HP Gasoline Water Pump

Negotiable MOQ: 20 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

JDP

Model Number:

5.5-11HP

Suzhou Jinding Machinery Manufacturing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name JDP

Model Number 5.5-11HP

Theory Other

Structure Other

Usage Water

Power Other

Standard or Nonstandard Standard

Fuel Gasoline

Application Other

Specifications

5.5HP~11HP gasoline water pump
1.round iron frame
2.chinese engine
3.Aluminium water pump
4.2inch,3inch,and 4inch water pump

Model	WP-20	WP-30	WP-40
Outlet Size(mm/inch)	50/2	80/3	100/4
Inlet Size(mm/inch)	50/2	80/3	100/4
Speed(rpm)_	3600	3600	3600
Max.Flow Rate m3/h/GPM	21/92.5	60/264	80/353
Lift(m/ft)	30/98	30/98	25/82
Suction(m/ft)	7/23	7/23	7/23
Engine Model	JDP168F(E)	JDP168FA(E)	JDP182F(E)
Max.Output(HP)	5.5	6.5	11
Engine Type	4-Stroke,25°inclined Single-Cylinder with Air-cooled
Bore×Stroke(mm/inch)	68×45/2.67×1.77	68×54/2.67×2.12	82×64/3.2×2.5
Displacement(ml)	163	196	338
Ompression Ratio	8.5:1	8.5:1	8:01
Max Torque(N.m/rpm)	10.8N.m/2500rpm	13.0N.m/2500rpm	23.5N.m/2500rpm
Starting System	Recoil and hand-operated/Electric start
Ignition System	Non-contact transistorized ignition(T.C.I)
Fuel Tank Capacity(L/gal.)	3.6/0.95		6.5/1.72
Fuel Consumption(g/hp.h)	290
Oil Capacity(L/gal.)	0.6/0.16		1.1/0.29
Package Dimensions(mm/inch)	480×370×405/19×15×16	510×395×405/20×16×16.5	650×460×530/26×18×21
N.W/G.W(kg/lb)	25/26/55/57	28.5/29.5/63/65	44/45/97/100
