Small Generator/2KVA~5KVA Gasoline Generator

Negotiable MOQ: 20 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

JDP

Model Number:

JDP2500~6500E

Suzhou Jinding Machinery Manufacturing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name JDP

Model Number JDP2500~6500E

Output Type AC Single Phase

Speed 3000/3600RPM

Frequency 50/60

Rated Power 2KVA~5KVA

Rated Voltage 110/120/220/230/240V

Rated Current 18-45A

Specifications

2KVA~5KVAGasoline Generator
1.electric start
2.round pipe frame
3.Air cooled
4.open type

Model		JDP2500(E)	JDP3500(E)	JDP4500(E)	JDP5500(E)	JDP6500(E)
Generator	Type	Revolving Maginetic Field,Self-excitating,2-pole,Single-phase
	Voltage Regulation	Capacitance/AVR
	Frequency(Hz)	50/60
	Max.AC Output(KVA)	2.2/2.5	2.8/3.0	3.8/4.0	4.5/5.0	5.5/6.5
	Rated AC Voltage(V)	110/120/220/230/240
	Rated AC Output(KVA)	2/2.2	2.5/2.8	3.5/3.7	4.0/4.5	5.0/5.5
	Power Factor cosφ
Engine	Model	JDP168F(E)	JDP168FA(E)	JDP177F(E)	JDP182F(E)	JDP188F(E)
	Type	Single-cylinder 4-stroke,25°inclined with Air-cooled
	Displacement(cc)	163	196	270	338	389
	Max.Output(HP)	5.5	6.5	9	11	13
	Fuel	Unleaded Gasoline
	Fuel Tank Capacity(L/gal)	15/4.0		25/6.6
	Oil	SF or Higher Grade
	Oil Capacity(L/oz)	0.6/20		1.1/37
	Ignition System	Non-contact transistorized ignition(T.C.I)
	Starting System	Recoil or electric start
Standard Features	Fuel Gauge	0
	Voltmeter	0
	AC Circuit Breaker	0
	Low Oil Level Protection	0
	Engine Switch	0
	DC Output 12V/8.3A	0
	DC Circuit Breaker	0
	AC Socket	0
Optional Features	Pilot Light	+
	Remote Control	+
	GFCI Socket	+
	Handle&Wheels	+
	Hours meter	+
Package	Dimension(L×W×H)(mm)	610×460×510 24.1×17.7×18.5		695×525×560 28.0×20.1×22.9
	G.W(kg/lbs)	47/103	51/112	85/187	86/189	88/194
	N.W(kg/lbs)	45/99	49/108	82/180	83/182	85/187
