3KW/5KW Open Type Diesel Welding Generator Set

Suzhou Jinding Machinery Manufacturing Co., Ltd.

Negotiable MOQ: 3 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

JDP

Model Number:

GFW-2/GFW-3/GFW-5/GFW-8/GFW-10/GFW-12

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name JDP

Model Number GFW-2/GFW-3/GFW-5/GFW-8/GFW-10/GFW-12

Output Type AC Single Phase

Speed 1500/1800

Frequency 50/60

Rated Power 2kw~12kw

Rated Voltage 230

Specifications

1) It is very convinient to use
2) It can just be used as a generator ,also can be used as a welder
3) Move easily

Model		GFW-2	GFW-3	GFW-5	GFW-8	GFW-10	GFW-12
Rated output		2	3	5	8	10	12
Diesel Engine	Model	170F(M)	R175(NM)	195(NM)	S1100(NM)	ZS1110(NM)	ZS1115(NM)
	Rated Output(kw)	2.94	4.4	8.8	11.32	14.7	16.2
	Fuel Consumption(g/kw.h)	292.3		257		248.2	246
	Cooling Method	Air/water-cooled		Evaporation or Radiator
	Starting Method	Hand cranking or electric starting with battery
Welding& Generating	Model	SD-2	SD-3	SD-5	SD-8	SD-10	SD-12
	Rated Output(kw)	2	3	5	8	10	12
	Rated Voltage(V)	230	230	230	230	230	230
	Rated Current(A)	8.7	13	21.8	34.8	43.5	52.2
	Frequency(Hz)	50/60	50/60	50/60	50/60	50/60	50/60
	Power Factor	1	1	1	1	1	1
	speed (rpm)	1500/1800	1500/1800	1500/1800	1500/1800	1500/1800	1500/1800
	Phase Connection	1-Phase
	Excitation	Harmonic Excitation
Idle Voltage in welding(V)		75	75	80	80	80	80
Current in welding(A)		80	120	160	200	230	300
Working Voltage in Welding(V)		25-30	25-31	25-32	25-33	30-35	30-35
Continuous Load Rate(%)		40	40	40	40	40	40
Welding Current Adjusting Range(A)		50-100	60-140	70-180	80-210	100-280	140-320
G.W/N.W(kg)		150/130	170/150	360/320	380/340	400/360	420/380
Packing size(L×W×H)(mm)		1000×520×650		1350×710×760		1400×710×760
