Grain Seed Cleaning Machine Made In China

FOB Price

USD $18,000 - $23,000 / Set

1 Set(Min.Order)

Product Details

Type:	Grain/seed Cleaning Equipment	Use:	For cleaning grain(seed)	Certification:	ISO9001:2008, etc
Place of Origin:	Hebei, China	Brand Name:	SYNMEC	Model Number:	5X-12
Condition:	New	After-sales Service Provided:	Engineers available to service machinery overseas

Grain Seed Cleaning Machine

INTRODUCTION of Grain Seed Cleaning Machine

The 5X series Grain Seed Cleaning Machine is a universal machine well suited for pre- and fine cleaning many different species of grain and seeds.

The standard design of the machine is provided with both pre and after suction units.

Quick screen changing from pre-cleaning into fine cleaning by the operator serves to optimize the cleaning tasks.

The 5X series Grain Seed Cleaning Machine is a very competitive machine, both as regards price and capacity as well as function and operation.

The technology of the machine is thoroughly tested, which can be documented by many references all over the world.

SPECIFICATION of Grain Seed Cleaning Machine

Model	5X-5	5X-12
Dimension(L×W×H)	3200×1920×3600 mm	3790×1940×4060 mm
Overall weight	3250 kg	3600 kg
Rated capacity	5 t/h	12 t/h
Overall air volume	8200 m3	12520 m3
External air blower	4-72N0-6A, 7.5 kW	4-79N0-6A, 11kw
Vibration sieve motor(gear motor)	2.2 kW	2.2 kW
Back lifting system motor	3.0 kW	3.0 kW
Feeding motor	1.5 kW	1.5kw
Total Power	6.7 kW	6.7kw
Air Blower Type	centrifuge air blower
Top air blower Rotary speed	4-79NO6A,1400 r/min
Back lifting air blower Rotary speed	100~1000 r/min
Screen Type	piercing screen
Screen Dimension (L×W)	800×1250 mm
Frequency	300(80~400) times/min
Amplitude	30 mm
Layers and number	4 layers,7 pieces	5 layers,15 pieces
Screen number and type
level 1	1 piece round hole	3 pieces slot hole
level 2	2 pieces slot hole	3 pieces slot hole
level 3	2 pieces slot hole	3 pieces slot hole
level 4	2 pieces slot hole	3 pieces slot hole
level 5	null	3 pieces slot hole

Hebei Ruixue Grain Selecting Machinery Company Limited: Contact nameTony Zhou; Phone86-311-67663887; AddressBaifo East Street,Chang'an District Shijiazhuang,Hebei
