13.56mhz contactless RFID access control card short range rfid reader
Host interface |
USB or serial RS232 |
operating range |
0°C to +50 °C |
storage range |
-40 °C to +85 °C |
humidity range |
30 % to 95 % non condensing |
Smart card interface |
ISO 7816 T=0 T=1 protocols, support popular memory cards in the market. |
Contactless |
ISO 14443 TYPE A&B or ISO15693 (13.56MHZ) |
power supply voltage |
DC5V |
power supply current |
<100 mA |
BPS |
9600-115200bps |
Operation systems |
Windows 98/me/2000/NT/XP, UNIX, LINUX |
operating distance (contactless) |
up to 5 cm |
The D8 includes RS232 and USB port connections. It is used as a contactless smart card reader in generally, but it can be expanded dual Mode Smart Card Reader. Meantime D8 can adds 2-3 SAM cards for choice of consumer. It includes an antenna, LEDs and a buzzer. All the Mifare cards can be read and written. The ISO 14443 type A and B cards can also be accessed on request. It is mainly used in parking-meter, door-control, Health care—medical identification, transportation, oil-control, access control identifications.
Packing information:
For CR80 standard cards:
250pcs per box.
20 boxes (5,000pcs) per Export standard carton (48x22.5x30cm).
* If the card is not CR80 standard or with special deallings please ask our clerk for packing details
Delivery:
We accept multiple ways to make sure the cards delivered to your hand safely in time.
Payment:
Usually we use T/T to HSBC but also accept peyment as your requirement.
How long will it take to get your price?
We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.
How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality.
If you just need a blank sample to check the design and quality, we will provide you sample for free, freight collected.
If you need the samples with you own printing, we will charge some sample fee based on your printing.
What kind of files do you accept for printing?
AI, PDF, CDR, high resolution JPG
How long can I expect to get the sample?
After you pay the sample charge and send us confirmed files, the samples will be ready for delivery in 3~5 days. The samples will be sent to you via express and arrive in 3~5 days. You can use your own express account or prepay us if you do not have an account.
What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order. Generally speaking, production lead time is within 1~2 weeks.
What is your terms of delivery?
We accept EXW, FOB, CIF, etc. You can choose the one which is the most convenient or cost effective for you.
Terms of payment?
T/T, L/C, Escrow or others according to your requirement.
To save time, you can contact us direct as followings:
Mr. Ted
| Tel: | 86-755-29824686/ 29823378/ 23603626 |
| Cel/WhatsApp: | 86-15391809491 |
| Skype: |
szvipcard2008 |
| TM: | cn1000563126 |
We will provide soonest and positive service for you!
