2ton Lpg and Gasoline Forklift Truck

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

Weifang Fumei Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO CHINA

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name FM

Model Number CPQYD20G

Type Other, LPG/Gasoline forklift truck

Power Souce Gasoline Engine

Rated Loading Capacity 2000KGS

Max. Lifting Height 7300MM

Min. Lifting Height 3000MM

Fork Length 1070MM

Fork Width 120MM

Overall Dimensions 3520*1150*2160MM

Certification CE and ISO9001 certification

After-sales Service Provided No overseas service provided

Specifications

LPG/Gasoline/GLP forklift/empilhadeira:
1, China engine or Nissan engine
2, LPG or gasoline as fuel
3, more streamlined

2tons LPG and Gasoline forklift truck/GLP forklift/empilhaderia/auto elevador/montacarga Specification:

MODEL		CPQYD20G
Load capacity		2000 kg
Load center		500 mm
Power type		Gasoline/LPG
Max. lifting speeds(with load)		400 mm/s
Max. driving speeds(with/without load)		17/19km/h
Max towering (with load)		14.5/9.8kn
Grade ability(with load)		15/20%
Lifting height (H₁)		4500 mm
Free lift		1500mm
Tilting angles(forward α-backward β)		6/12
Min. turning radius		2200mm
Min. Right angle aisle width		1950mm
Min. under-clearance		110mm
Dimensions	Overall length(including fork) (A)	3520 mm
	Overall width (B)	1150 mm
	Overall height(mast lowered) (H)	2160 mm
	Overall height(mast extended) (H₂)	5560 mm
Overall height to overhead guard (H₃)		2165mm
Fork overhang (A₁)		450 mm
Wheel base (A₂)		1640 mm
Tread	Front tread (B₁)	970mm
	Rear tread (B₂)	970mm
Tire	Front tire	7.00-12
	Rear tire	6.00-9
Total weight		3320 kg
Fork width (B₃)		122mm
Fork thickness(H₄)		40mm
Backrest height		1000mm
Fork length(A₃)		1070 mm
Engine	Engine model	CHINA ENGINE/NISSAN K25 ENGINE
	Rated power	37/40kw
	Rotate speed at rated power	2650/2400 rpm
	Max. Torque	≥148 nm
	Rotate speed at max. Torque	1800~1900 rpm
Type of power shift		Tor-con
Packing details	4PCS/20’CNT; 8PCS/40’CNT

OPTIONAL ITEMS
Mast	2-STAGE MAST 3M 2-STAGE MAST 3.3M 2-STAGE MAST 3.5M 2-STAGE MAST 4M 3-STAGE MAST 5M 3-STAGE MAST 5.5M 3-STAGE MAST 6M 3-STAGE MAST 7.3M
Fork	1220 MM FORKS 1370MM FORKS 1520 MM FORKS 1820 MM FORKS 2000 MM FORKS
Accessories	side shift; fork positioner, etc.
Other items	solid tire, cab with fan or heater, etc.
