Adjustable micro sprayers have adjustable flow rates of 0 to 24 GPH @ 15 to 30 PSI with a spray pattern of up to 13’ diameter in a 360-degree pattern. When the cap is rotated counter-clockwise the flow and the radius of the soaked area can be adjusted from a small diameter with gentle umbrella pattern up to 13' diameter full circle.
SPECIFICATION
- Assembly : 1/4" barb or 5” stake with barb outlet
- Droplet Size: Large
- Flow rate: 0 to 24 GPH @ 15 to 30 PSI with coverage of 0 to 13' diameter
- Fully open : Approximately 22 clicks
- Pattern: 360°
- Recommended filtration: 120 mesh
- Recommended pressure: 10 to 30 PSI
- Trajectory Angle: Flat
FEATURES
- Available on 1/4" barb or with 5” stake with 1/4" barb
- Can be attached into the end of 1/4" micro tubing or into the 1/2" drip tubing.
- Can be replaced with one of three available sprayers
- Constructed of UV-resistant durable plastic materials, ensuring resistance to most chemicals and fertilizers used in landscape applications
- Heavy duty adjustable flow control feature allows changing of flow rates and diameter depending on plant requirements
- Trouble free operation with no moving parts
DESCRIPTION
The Drip Store has a wide range of adjustable micro sprayers and jets to meet all of today‘s requirements for micro irrigation needs. Built-in adjustable flow control to control the distance or radius can adjust the water flow from 0 to 24 GPH and the diameter up to 13'. The no moving parts adjustable micro sprayers can be used for a wide range of applications and are available with a 360° pattern for small to large diameter and for watering that requires small droplet size with low precipitation rates. This allows the changing of the flow rate for each individual sprayer from off to full flow.
When low volume overhead irrigation is desired for an area where drip emitters are not practical and micro sprinkler diameters and moving parts are not required nor preferred, the adjustable micro sprayers may be what is needed. Like micro sprinklers, micro sprayers and jets are available in a wide variety of styles, flow rates, diameters, and configurations. Like micro sprinklers, they operate at low pressure and require a filter to protect the small orifice of the adjustable sprayer from clogging. The main advantage of adjustable micro sprayers to some users could be the lack of moving parts and the feature of adjustable flow rates.
APPLICATIONS
This series of adjustable micro sprayers has no moving parts and can be used in home gardens for ground cover, flowerbeds, shrubs and trees.
INSTALLATION VIDEO
INSTRUCTION
Installation for Umbrella Adjustable Sprayers
To install the micro sprayer with the barb use one of our poly riser assemblies available in our accessories section and install it a minimum of 4” above ground. The adjustable sprayer can be adjusted from 0 to 22 GPH at 20 PSI. When the cap is rotated counter-clockwise the flow and the radius of the wetted area can be adjusted from a small diameter gentle umbrella pattern up to 13' diameter full circle. Twisting the dial on the sprayer towards the "+" or the " -" signs will allow you to increase or decrease the flow.
