Product name: High and low temperature impact test chamber
Environmental Test Constant heat chamber specification
| Product Name | Model | External Size (mm) D × W × H | Studio Size (mm) D × W × H | Voltage | Power(KW) | Temperature and humidity range | Other technical parameters |
| High and low punch Strike chamber | GDC4005 | 880*730*1440 | 350×400×400 | 220V 50HZ | 2.5 | The impact of temperature:-20℃-+150℃ |
Temperature fluctuation: ≤ ± 0.5 ℃ Temperature uniformity: ≤ ± 2 ℃ Recovery time: ≤5min |
| GDC4010 | 980*830*1560 | 450×450×500 | 380V 50HZ | 3.5 | |||
| GDC6005 | 920*750*1460 | 350×400×400 | 220V 50HZ | 4 | The impact of temperature:-40℃-+150℃ | ||
| GDC6010 | 1020*850*1660 | 450×450×500 | 220V 50HZ | 4.5 | |||
| GDC8010 | 1520*1450*2310 | 1000*1000*1000 | 380V 50HZ | 8.5 | The impact of temperature:-65℃-+150℃ | ||
Environmental Test Constant heat chamber character
1 applies to electronic components, semiconductors, electronic circuit boards, metal and other materials industry tests.
2. the lower chamber for low temperature region, the upper part of the high temperature zone, the specimen is placed in the central chamber, the impact on the throttle open at high temperatures, the formation of the high-temperature cycle. When the temperature impact, the throttle is closed, under the throttle open, the formation of the low-temperature cycle. If required can also be connected with the ambient temperature, the formation of three box method tests.
3 specimens can be stationary, avoiding the user moves the specimen due to the inconvenience caused.
4 imported totally enclosed fan cooled compressor, imports may touch temperature control.
5 studio mirror stainless steel plate, shell electrostatic spraying.
