Mechanical Stamping Sawdust Wood Pellet Machine consist of belt loading type and screw loading type.
| Model | cdr-75b |
| Main parts | Briquetting machine |
| Conveyer | |
| Control cabinet | |
| Briquette Specification | Dia.:8mm, 70mm |
| Capacity | 500 kg/hr for 8mm wood pellets; 1t/hr for 70mm briquettes |
| Density | 1000-1300kg/m3 |
| Power of main engine | 62KW |
| Weight | 7000kg |
| Overall dimension | Host machine: 3.4mX2mX1.8m Control cabinet: 1.2mX0.6mX1.2m. |
| Number of operator | 2 |
| Installation space | About 80m*m |
Production of Moulds with Different Pore Size
| Mould (Pore Size) | 8mm | 10mm | 22mm | 30mm | 70mm |
| Hole Number | 61 | 37 | 7 | 4 | 1 |
|
capacity (kg) (Material is sawdust with moisture15%)
|
500 kg | 600kg | 800 kg | 880 kg | 1000 kg |
Before briquetting, most raw materials need to be crushed into small fragments (≤20mm) and materials such as shells and kernels do not need to be crushed. The moisture percentage should be kept from 10% to 20%. Through feeding conveyor, the fragments will be sent to screw feeder and then be pushed into the inlet of briquette press machine. Then fuel briquettes will be formed.
Photos of Finished Pellets / Briquettes
Advantages:
1. Alternative power supply: Mechanical Stamping briquette machines can be driven by either electric motor or diesel engine to meet the demands from different clients.
2. Combined with automatic auxiliary equipment, the briquetting productivity can be enhanced impressively.
3. Alternative finished products: the series stamping briquette machines can produce either biomass pellets or briquettes.
4. An extensive spectrum of material application: both agro and forestry waste can be manufactured by the series briquette machines. Namely, as follows:
Agro waste: cotton stalks, corn cobs, soybean straw, sorghum stalks, millet stalks, rice husks, peanut shells, wheat straw etc.
Forestry waste: wood shavings, bagasse, pomace, pulp sludge, pasture, bark, bamboo shavings, sawdust, leather scraps, etc. All the raw materials above can be processed into pellets and briquettes, with a higher fuel value suitable for domestic fireplaces, small and medium sized biomass boilers and industrial power and heating productions.
5. Long service period: made of special alloy steel feature high degree of wear resistance, the mould lifespan can be utterly prolonged.
6. Of the series, 2 main types of briquette press can be chosen: the extruding briquette machines with abrasive disc and the mechanical stamping briquetting machines. The abrasive disc extruding type can generally be further divided into three kinds: Ring die design, flat plate design, and ring & flat die design. The diameter of briquettes produced by abrasive disc extruding briquette machines is 30mm * 30mm, while the diameter of mechanical stamping briquetting presses can reach 80mm.
7. Moreover, the shape of mechanical stamping briquettes is diverse, round, square, hexagonal, perforated and other tailored forms.
8. Produce biomass briquettes (φ70mm/φ30mm) and pellets (φ8mm/φ10mm/φ22mm) with different diameters through different molds, which are easy to be changed within 30min.
