Chengda Factory Supply Directly 22kw 800-1100kg/h Output Hammer Mill Tree Branch Crusher

Chengda Factory Supply Directly 22kw 800-1100kg/h Output Hammer Mill Tree Branch Crusher thumbnail-1
Chengda Factory Supply Directly 22kw 800-1100kg/h Output Hammer Mill Tree Branch Crusher photo-1
US$ 700 - 7,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
Chengda
Contact Supplier Request Quote Chat Now
Laizhou Chengda Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shandong, China
Brand Name Chengda
Model Number CF500
Voltage 380V
Power(W) 22kw
Dimension(L*W*H) 124*97*106cm
Weight 630kg
Certification CE ISO9001
Warranty 1 year
After-sales Service Provided Overseas service center available

Specifications

Low Break Down
CE certification



Introduction to CF500 Electric Hammer Mill

Chengda factory supply directly 22kw 800-1100kg/h output hammer mill tree branch crusherThis CF500 hammer mill is newly developed machine which is endowed with many advantages compared to other kind of crushers such as simple construction, convenient operation, high efficiency, saving power consumption, and safe condition. It is suitable to crush raw and hard materials with big size such as tree branches, bamboo, wood scrap, wood brick,old cardboard and newspaper, straw, crop stalks and corn cobs and so on. After crushing, raw materials are uniform and with proper moisture content to meet further processing. With capacity 800-1100kg/h, it is can surely meet the production requirement in the farms, middle sized feeding factory or family.



 Key Features of CF500 Electric Hammer Mill
Chengda factory supply directly 22kw 800-1100kg/h output hammer mill tree branch crusher





1. With capacity 800kg---1100kg/h, this hammer mill can satisfy a large production demand on a daily basis.





2. The ability to change screen size, and the option of a variable speed frequency drive control, enable processing a variety of materials using the same hammer mill.





3. Both coarse and fine grinding can be realized through adjusting the gap between hammers and screen.





4. The core part ---the hammer flake is scientifically designed to have two concussion parts, thus when one part is worn out, you can turn over to use the other part.



5. The angle of the screen can be 180° which allows for high throughput at lower power consumption.





6. Equipped with air blower, the crushed material can be directly collected and transported to next machine for further processing.







Model No. Power Electric Engine 50HZ  Wood output(kg/h) N/G weight(kg) Sieve screen size Sieve screen specification Packing Size(cm)
CF158 3 phase 2.2kw  60-120 75/95 360*160mm 1.5-10mm 48*58*63
CF198 3 phase 4kw 200-300 120/140 510*200mm 2-10mm 90*58*102
CF198 7.5HP gasoline engine 200-300 120/140 510*200mm 2-10mm 96*62*105
CF420B 3 phase 7.5kw 200-400 260/320 680*280mm 1.8-10mm 112*82*107
CF420C 3 phase 11kw 200-500 320/360 680*280mm 2-10mm 112*82*107
CF420A 15HP Diesel engine 300-500 330/360 680*280mm 1.8-10mm 147*73*109
CF420A 22HP Diesel engine 300-500 350/390 680*280mm 1.8-10mm 147*74*111
CF500A 55HP Diesel engine 800-1100 800/840 820*390mm 2-10mm 150*142*123
CF500 3 phase 22kw 800-1100 600/630 820*390mm 2-10mm 124*97*106



Chengda factory supply directly 22kw 800-1100kg/h output hammer mill tree branch crusher

 Diesel engine hammer mill/ wood crusherChengda factory supply directly 22kw 800-1100kg/h output hammer mill tree branch crusher

  Chengda factory supply directly 22kw 800-1100kg/h output hammer mill tree branch crusher Chengda factory supply directly 22kw 800-1100kg/h output hammer mill tree branch crusher

 After-sale Service
After-sale service can ensure a smooth business once you buy a machine aboard. You can inevitably encounter some operation problems while making wood pellets. Amisy can offer you 12 months warranty for main parts to protect your interests and save your money.

 Chengda factory supply directly 22kw 800-1100kg/h output hammer mill tree branch crusher
Chengda factory supply directly 22kw 800-1100kg/h output hammer mill tree branch crusherChengda factory supply directly 22kw 800-1100kg/h output hammer mill tree branch crusher

Chengda factory supply directly 22kw 800-1100kg/h output hammer mill tree branch crusher

Chengda factory supply directly 22kw 800-1100kg/h output hammer mill tree branch crusherChengda factory supply directly 22kw 800-1100kg/h output hammer mill tree branch crusher
