Home > Products > wood crusher > Factory supply directly wood crusher machin, wood crusher for pellets, CF198
Factory supply directly wood crusher machin, wood crusher for pellets, CF198
- 2000 Set / Sets per Month
- qingdao
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Place of Origin: | Shandong, China | Brand Name: | Chengda |
Model Number: | CF198 | Voltage: | 380V, 380v | Power(W): | 4kw |
Dimension(L*W*H): | 90*58*102cm | Weight: | 140 | Certification: | ISO CE |
Warranty: | one year | After-sales Service Provided: | No overseas service provided |
Product Description
Factory supply directly wood crusher machin, wood crusher for pellets, CF198
Wood Hammer Mill With Cyclone | |||||||||||||||||||||||||||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Model: CF500 Voltage: 380V Capacity:800-1100kg/h Packing Size: 124*97*106cm | |||||||||||||||||||||||||||||||||||||||||||
Model: CF420 Voltage: 380V Capacity:200-500kg/h Packing Size: 112*82*107cm | |||||||||||||||||||||||||||||||||||||||||||
Model: CF198 Voltage: 380V Capacity:200-300kg/h Packing Size: 97*75*84cm | |||||||||||||||||||||||||||||||||||||||||||
Specifications | |||||||||||||||||||||||||||||||||||||||||||
The hammer mill is fixed with an engine with a power of RP-driven all kinds of different power. Its working principle is: after the raw materials were put into crushing chamber, the high-speed operated hammer sheets will impact the raw materials over and over again, then the raw materials will be crushed into pre-set size step-by-step. The sieve have the following size: 1.5mm, 2mm, 4mm and 6mm. Then the crushed materials will leak out from the sieve. The draught fan will convey the leaked materials into separator centrifuge, finally, the powder will be discharged down. | |||||||||||||||||||||||||||||||||||||||||||
All KL Series Wood Hammer Mills | |||||||||||||||||||||||||||||||||||||||||||
|
CF500 Wood Hammer Mill |
---|
This CF500 hammer mill is newly developed machine which is endowed with many advantages compared to other kind of crushers such as simple construction, convenient operation, high efficiency, saving power consumption, and safe condition. It is suitable to crush raw and hard materials with big size such as tree branches, bamboo, wood scrap, wood brick,old cardboard and newspaper, straw, crop stalks and corn cobs and so on. After crushing, raw materials are uniform and with proper moisture content to meet further processing. With capacity 800-1100kg/h, it is can surely meet the production requirement in the farms, middle sized feeding factory or family.
|
The Hammer Mill Cutter and Sieve |
Wood hammer mills are able to crush both forestry and agricultural material, brittle and fibrous material, such as bamboo, stalk, grass and shrub. A screen with cutting edges is used to control the wood particle size. If the size is larger than screen, these material will be sent back to be grinded again until they can get though the screen. The size of the grinded material depend on the size of screen and the rotation speed.
|
In actual production, a cyclone is always a necessary device in wood hammer mill. What’s the function of cyclones? How does it work? Does the cyclone really work?
Cyclonic separation is a method to remove wood particles from air steam though vortex separation without filters. In wood chips and sawdust collection, rotational effects and gravity are main ways to separate the mixed air flow. This method can be also used to separate fine droplets of liquid from a gaseous stream.
A high speed rotating airflow is established within a cylindrical or conical container called a cyclone. Airflow begins at the tops of cyclone and ends at the bottom, moving in a spiral way. Wood particles out from wood hammer mill are drew up into airflow starting separation procedure. Wood chips and sawdust in the rotating steam have much inertia to follow the moving airflow. They will strike the inner wall until falling to the bottom, waiting to be collected.
The main advantage of cyclones is to reduce the dust content in air to protect your lungs and breathing system. Pneumoconioses and black lung disease are all cause by long term exposure to dust. Please taking heath into consideration when purchasing a wood processing machines. |
CE Certification of Wood Hammer Mills |
---|
Packing & Delivery | |
---|---|
To make sure the machine delivery to you at the best condition, we adopt the considerate way to protect the equipment very well. We consider our products just as our children. |
About our company | |
---|---|
Laizhou Chengda Machinery Co., Ltd was founded in 1992, which is a high tech that enterprise integrates new product design, development, manufecturing and international trade business. Main products: flat die pellet mill, vertical ring die pellet mill, wood chipper, hammer mill, pellet cooler and cutting wood machine etc.. Our company always takes the product quality and credibility as the foundation of us present and tomorrow survival and development. We always adhere to the "quality and reputation first" concept.And we have got the 'quality advanced company" and "quality trustworthy company" and the "honorary company". we are AAA level enterprise to be named by the national quality, reputation and service department Our company is located in Laizhou Bay, near to Qingdao seaport. It's convient in sea, road, and air transportation, we have very perfect import and export service system in China. At the same tine , we have a widely range of commodity information network, partners all over the world. Believe our sincere cooperation will creat a better tomorrow. |
Contact (Miss.) Julia Yuan | |
---|---|
Salesdirector: julia yuan Skype: lzhcjulia001 Tel: +86-18615975058 Whatsapp: 008615764256578 Address: Address:Sanlihezi, Wenfeng District, Laizhou, Shandong Province,China |
