Wood Chipper
| Initially, wood chipping was mainly used for the efficient removal of branches and green waste in areas such as parks and woodland, but as wood chip came to be regarded as an important natural resource, wood chipping has taken on a new, ecomomic dimension. Wood chip is valuable if the quality is consistent and meets designated requirements. DWC wood chippers ensure these requirements are met. Our entire product range is designed to deliver high quality wood chip and on many of our machines the knives can be adjusted to produce different sizes, depending on what the wood chip wii be used for. Large quantities of wood chip are already being used as a fuel supply for energy and heating, and for industrial purposes such as MDF board and paper production. In addition, wood chip is extensively used as ground cover or as surfacing material for paths as an environment-friendly weed killer, which reduces or eliminates the need for chemical sprays. |
Features
| 1. Low noise. |
| 2. CE approved. |
| 3. Long service life. |
| 4. Good after-sale service. |
| 5. Move it anywhere you want. |
| 6. Set it freely for little space. |
| 7. Good quality & Stable performance. |
| 8. Capacity 90-120kg/h suitable for home use. |
Specifications
Model No | CFD-8 | CFD-8 |
Max diameter of feeding | 8” (200mm) | |
Matched Tractor Power | Tractor (18~100hp, 540/720 rpm) | |
Diameter of Chipper disk | 600mm | |
Turing speed of chipper disk | 1080rpm / 1410rpm | |
Feeding system | Hydraulic Feeding | Feeding by worm Reduction |
Adjustable speed | Gear (4mm/s) | |
Stop-Reverse-Forward Function | Only Forward Function | |
Blade material | Durable chromium CR-12 | |
Output sawdust size | Thickness < 4mm | |
Rotation Angle of Discharge Spout | 360° | |
Weight | 450KG | 420KG |
Working efficiency | 8~9 m³/h | 6~9 m³/h |
Volume of Tank | 26L | / |
Package Dimension | 1150*900*1300mm | 1150*900*1300mm |
Model No | CFD-18 | CFD-22 |
Power | 18HP | 22HP |
Engine | Single cylinder diesel engine with electric start | Single cylinder diesel engine with electric start |
Max Diameter of feeding | 8” diameter (200mm) | |
Feeding system | Mechanical / hydraulic | |
Rotor plate size | 640mm | |
Rotor plate weight | 82KG | |
Knives (blades) number | 1 stationary knife (blade), 2 movable knives (blades) | |
Materials of blades | Durable Chromium CR-12 | |
Dimension of discharge hopper | 1700x1100x1100mm | |
Dimension of feeder hopper | 200x220mm | |
Height of discharge spout | 1800mm | |
Rated RPM | 1080 | |
Rotation Angle of Discharge Spout | 360° | |
Working efficiency | 6-11CBM/H | |
Gross weight | 640KG | 660KG |
Chippers Overview
Packing & Delivery
Wood Chipps Effect
About our company
Laizhou Chengda Machinery Co., Ltd. is one of the most earliest manufacturer of wood /feed machinery in China. With a wide range, good quality, favorable prices and stylish designs,our products are extensively used in agriculture and other industries. Please feel free to visit our production facility in Laizhou Shandong, we sincerely welcome tours! |
After- sale service
| After-sale service can ensure a smooth business once you buy a machine aboard. You can inevitably encounter some operation problems while making wood pellets. Chengda can offer you 12 months warranty for main parts to protect your interests and save your money. |
