Scrap copper wire granulator recycling machine
1. Brief introduction of Scrap copper wire granulator recycling machine
The scrap electric and copper wire separator is the equipment that separating the scrap wire metal and plastic. Because the final products are similar to rice particles, so this machine is called copper wire granulator. It is one of the environmental protection machines. The machine has two types, one is dry type and another is wet type. This equipment can completely separate the copper and plastic, and realize the integrated utilization. It has higher economic benefits. No dust and no secondary pollution.
2. Technical parameters of copper wire granulator machine
Model |
Capacity |
Power |
Voltage |
Weight |
Dimension |
Separation rate |
400-N1 |
150-200kg/h |
22.45kw |
220V,380V |
1500kg |
2700x1900x2300mm |
99.9% |
600-A |
300-400kg/h |
36kw |
220V,380V |
3400kg |
3500*2000*2700mm |
99.9% |
800 |
500-600kg/h |
75kw |
220V,380V |
6800kg |
5500*4500*3300mm |
99.9% |
3. Features of copper wire granulator machine
- Compact structure, beautiful shape, reasonable layout and convenient installing;
- Adopts PLC control system, intelligent operation which can make the equipment feed uniformly.
- Crushing machine uses roller crushing system, slow-speed of revolution, high capacity, low noise and simple operation.
- Crushing, separating and dust collecting equipments adopt combinatorial flat form, easy to move and transport, also increasing the inflexibility of the equipments.
- Separation rate of the equipment is as high as 99.9%.
- Feeding back system can make the semi-finished product regrinding, which ensure the totally separation of the metal and nonmetal products.
- Dust collection devices can control dust overflow, so the dedusting rate is as high as 99%.
1). This machine can be applied in what size of wires?
This copper wire granulator can be used to process 1-20mm diameter scrap wires;
2). How about scrap electric and copper wire separator applications?
This machine can process large cables, scrap copper wires, electric wires, ect;
Quality guarantee terms: Quality guarantee is one year. Spare parts we supply at factory cost lifetime.
We will be responsible for any broken which are caused by machine-self and quality problem, other situations which are caused by wrong operation, man-made problems etc will be in buyer’s response, and we will help to solve by video ASAP. If big problem we will send engineer to working site within one week.
Warranty:
Packaging: Wooden Box or Crate or bare package in standard containers for export;
Shipping: All machines will be sent by sea, if you need other kind of transportation, please inform us in advance. And all machines would be shipped in 7 days after the receipt of payment. Before and after shipping, we will take photos of machines and send photos to client.
200 model:
400 model:
600 model:
packing site:
Spare parts: (blades and screen)
Wire stripping machine:
If you are interested in our copper wire granulator machine, pls contact me feel free.
