big size hydraulic heat press machine heat transfer printing machine FJXHB4-2

Specifications

big size hydraulic heat press machine heat transfer printing machine
No air compressor required, silent working.
Teflon-coat

big size hydraulic heat press machine heat transfer printing machine   FJXHB4-2



Specification:
Model No.	FJXHB4-2
Machine Type	big size hydraulic heat press machine heat transfer printing machine
Controller	Digital Time & Temp. Controller
Voltage	220V/ 380V
Power	9kW
Time Range	0-60sec.
Max. Temp.	245°C (473°F)
Printing Area	600mm x 800mm(24"x31")/ 800mm x 1000mm(31"x39")/ 1000mm x 1200mm(39"x47")
	/1000mm x 1500mm(39" x 59")/1000mm x 2000mm(39"x79")
Gross Weight	500kg/ 540kg/ 700kg/ 930kg/ 1100kg
Package Size	1200mm x 900mm x 1600mm(50"x35"x63")/ 1400mm x 1150mm x 1550mm(55"x45"x61")/ 1620mm x 1260mm x 1550m(64"x50"x61")
	1880mm x 1310mm x 1600mmm(74"x52"x63")/ 2450mm x 1460mm x 1650mm(96"x58"x 65")
Application:
T-shirt, Puzzle, Mouse Pad, Metal Board, Coaster, Slipper, Bag, Cushion, etc.
Features:
1. Solid steel framework & stainless steel hardwares
2. Fully digital temperature & time control
3. Automatic alarm, temperature & time recycle
4. Teflon-coated thick heating platen, speed & even heater technology
5. Hydraulic drive, double large platforms, shuttle working table
6. Emergency release device and hydraulic regulator monitored
7. Heat & pressure averaged, thick item like ceramic supported
8. No compressor required, pressure greater and silent working
Strict Quality Control:
1. Each single heating rod is tested before being casted in an aluminum alloy.
2. Each single digital time & temp controller is tested before assembling.
3. All heat press pass high temp. test (200°C) for at least 20 minutes before packing.
Xinhong's Promises:
Xinhong's original intention is to support any of our customers, could deal with their heat transfer
business without interruptions. So Xinhong offers FREE SPARE PARTS with quantity order and
the following warranty:
1. Free life-time technical support on all heat press.
2. One-year warranty on entire press machine & spare.
3. Five-year warranty on castings, welds.
4. Five-year warranty on heating plate.
5. Six-month warranty on mug, plate, cap heat press machine.



The production line of our heat transfer machine :



Why choose us?

We have been manufacturing heat transfer machine (t-shirt heat transfer machine,mug heat  transfer machine,cap heat transfer machine ,plate heat transfer machine,etc.) for more than 10years,10+years R&D,strong technical supports on the OEM&ODM services. Our 9000sq.m new factories are equipped with china first class production line and strict quality control guarantees high quality ,enables high quality production. We also have one stop service for all sublimation products.

Worldwide agents available for overseas third party services. Welcome to join us !!
