NCE Server Cabinet
Comply with ANSI/EIARS-310-D, DIN41491; PART1, IEC297-2, DIN41494; PART7, GB/T3047.2-92 standard. Compatible with metric ETSI and 19 inch international standard.
APPLICATION
Widely applied in finance, securities and data center; adopted by the professional servers’ network providers as IBM, SUN, HP, COMPAQ, DELL etc.
MATERIALS
Cold-rolled steel sheet. Thickness for frame 0.8mm, mounting rail 1.2mm, smoky grey glass 5mm.
Technical specification
Exquisite design with precise craftsmanship.
Adjustable and heavy duty castors are available at the same time. Static
loading:300KG.
The top and bottom wiring channel can be closed and adjusted.
Vented front door and rear door enable ventilation and reliable operation.
Rack’s side panel can be easily assembled.
Surface finish: degreasing, pickling, phosphoric, powder coating.
Adjustable feet and heavy duty castors are available at the same time ,
static loading: 800kg.(with adjustable feet).
Height, width, and depth selectable, full range of optional accessories.
Part number configuration tool:
NCB18---66 ( 18U)
NCB 18-66 ( x) Use the x to specify the capability of the cabinets:
18= 18 U 22 = 22 U 27 = 27 U 32 = 32U 42=42U 46= 46u
