NCC 42U 19'' Network Cabinet
Comply with ANSI/EIARS-310-D, DIN41491; PART1, IEC297-2, DIN41494; PART7, GB/T3047.2-92 standard. Compatible with metric ETSI and 19 inch international standard.
APPLICATION
Widely applied in finance, securities and data center; adopted by the professional servers’ network providers as IBM, SUN, HP, COMPAQ, DELL etc.
MATERIALS
Cold-rolled steel sheet. Thickness for frame (Nine-fold section steel)1.5mm, mounting rail 2.0mm, side panel 1.5mm.
Technical specification
Surface finish: degreasing, pickling, phosphoric, powder coating. The thickness of powder coating is 80μm-100μm, complying with ROHS.
Curved perforated front door and double-section rear door enable equipment protection, reliable operation with entilation rate above 80% .
Nine-fold section steel for the frame.
Mounting rail and mounting angle finish: Electric galvanizing.
Top and bottom wiring channel can be closed and adjusted.Bottom plate with earthing wire.
Optional plinth to meet under-base wiring, ventilation and rat-proof.
Advanced lock. Efficient and solid cabinet connection.
Adjustable feet and heavy duty castors are available at the same time,static loading: 1000KG.
Full range of optional accessories.
Mounting rail with U mark.
Part number configuration tool:
NCB18---66 ( 18U)
NCB 18-66 ( x) Use the x to specify the capability of the cabinets:
18= 18 U 22 = 22 U 27 = 27 U 32 = 32U 42=42U 46= 46u
