Product Details
Max Payload: | 2000KGS | Size: | 5000x1750x1530mm | Place of Origin: | Jiangsu, China |
Brand Name: | Double Horse | Model Number: | SM-003 |
Product Description
DELUXE OFF ROAD HARD FLOOR CAMPER TRAILER
110% OFF ROAD COMPLY WITH ADR
PERFORMACE PARAMETER
Tare Mass(Kg) 1300 ATM(Kg) 2000
Wheel Base(mm) 3100 Angel of departure(degree) 27º
Coupling strength(Kg) 2000 People living number: 4~5
Ground clearance(mm) 567 Rear overhang (mm) 1210
Wheel track (mm) 1600 (Same wheeltrack with Toyota PRADO)
Overall measurements(mm) 4950x1850x1580 (LxWxH)
Body measurements(mm) 2245x1750x610 (LxWxH)
BASIC CONFIGURATION
Chassis
Material: RHS100x50x4mm 100x100x4mm 50x50x4mm
Fully welded and Fully hot dip galvanized chassis and frame
10 inch heavy duty solid swing up jockey wheel
3x 265/70R16 off road alloy wheel with brand new tyre
Spare wheel under Chassis with winch to drop down
Frame
Material: SHS25x25x3mm 40x40x4mm Angel steel 40x5mm Flat bar
2mm steel plate 70x50x6mm Angel steel
Off road overrun couplings with free rotate polyblock hitch
Gas struts assisted SS floor holder with 4 adjustable stabilizer legs
Aluminum check plate floor with pvc anti-smooth leather
Three popular Steel latches on each side to seal the top floor
Suspension
Strong independent coil spring suspension
With double action shock absorbers
Eccentric bolt for wheel toe-in & toe-out adjust
Nylon band restrain for coil spring over rebound
Brake
10 inch electric drum brakes with mannual SS cable brake
6 studs steel hub with PCD 139.7mm
10mm thick safety chain with certified Stamp
2000kg Parallel bearings & front Hand Brake
Full Off road 4x4 360 Degree Hitch inc towbar connection (2000kg rated)
Kitchen /Water Circuit
Full stainless steel external slide out sink holder,1500mm long
135L stainless steel water tank with food-qaulity approved water pipe
Copper tap for water outlet for hand wash
12V ele-water pump and copper tri-connector for water pipe
76mm wild heavy duty slid 220KG rate
Internal
1650x1950mm large queen size mattress inner spring @ 120mm thick
Lift up bed with gas struts
Very big side out drawer 1200x1100x140mm (184Liters)
4mm Aluminum decoration plate with white powder coating
2x tent bags of bed each side for storage
2x LED reading lights & 1x storage room (30L) with LED lights
5 YEAR CHASSISWARRANTY
Tent pole box
2mm thick Aluminum plate
1700x250x 100mm (Can put 30 PCS poles)
2mm SS cover on each side with latch
SS304 hinge for cover
Aluminum checker floor & SS floor holder
2mm thick Alu checker plate and full weld
Good qaulity floor carpet –anti combustion & anti skidding
SS 304 full welded floor holder with gas struts open
4 SS adjustable legs and 2 SS latch for floor holder lock
Floor holder can be used as luggage carrier
OUR FACTORY IS PROFESSIONAL CAMPER TRAILER MANUFACTURER.
IF YOU WANT DESIGN AND CUSTOMIZE YOUR CAMPER TRAILER , PLEASE FEEL FREE TO CONTACT US!
QAULITY BRANDS
DON'T BUY CHEAP, GET ONE AND LAST
