Round Medicine Particle Vibro Shaker Machine

Round Medicine Particle Vibro Shaker Machine photo-1
US$ 1,500 - 6,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Circular
Application:
Other, Medicine Particle Vibro Shaker Machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Qingdao Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Circular
Application Other, Medicine Particle Vibro Shaker Machine
Place of Origin Henan, China
Brand Name HENG SHUN
Model Number HYBZ-1000-2S
Voltage 220v, 380v or as your requirement
Power(W) 0.55kw
Dimension(L*W*H) 1160*1160*950mm
Weight 250kg
Certification ISO9001:2008, CE, BV
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Round Medicine Particle Vibro Shaker Machine
2.Energy saving, high efficiency
3.Rapidly replace the screen
4.No blockage



   Round Medicine Particle Vibro Shaker Machine



Introduction

Round Medicine Particle Vibro Shaker Machine

Hengyu is an innovative manufacturer of round medicine particle vibro shaker machine for the

chemical, food, pharmaceutical processing industries. Hengyu offers a wide range of auxiliary units

and systems for meeting special screening requirements.



Screening demo

Round Medicine Particle Vibro Shaker Machine

Round Medicine Particle Vibro Shaker Machine



Details onround medicine particle vibro shaker machine

Round Medicine Particle Vibro Shaker Machine

Round Medicine Particle Vibro Shaker Machine



Round Medicine Particle Vibro Shaker Machine





Technical parameters

Round Medicine Particle Vibro Shaker Machine

Model

Diameter

(mm)

Screen surface

Screen opening



Power

(KW)

Deck

Diameter

Area

(mm)

(m2)

HY-400

400

360

0.1017

5-500 mesh

0.18

1-4

HY-600

600

560

0.2461

0.25-0.55

1-4

HY-800

800

760

0.4534

0.55-0.75

1-4

HY-1000

1000

930

0.6789

0.75-1.5

1-4

HY-1200

1200

1130

1.0023

1.10-1.75

1-4

HY-1500

1500

1430

1.6052

1.50-2.20

1-4

HY-1800

1800

1730

2.3494

2.20-3.0

1-4



Feature

Round Medicine Particle Vibro Shaker Machine

1. Discharge the impurity and coarse materials automobile and operates continuously.

2. Unique screen flame design, long duration of screen, only 3 to 5min to replace the screen.

3. Impurities, coarse automatic discharge, it can be a continuous operation.

4. Different particles are graded automatically, so the auto-operation can be realized.

5. The outlet’s location can be adjusted to anywhere you need. It is very easy to form producing line.

6. Sieving machines can reach 5 layers, it is recommended to use 3 layers.



Round medicine particle vibro shaker machine applied in:

Round Medicine Particle Vibro Shaker Machine

Round Medicine Particle Vibro Shaker Machine



Production Technology

Round Medicine Particle Vibro Shaker Machine

Round Medicine Particle Vibro Shaker Machine



Notice

Round Medicine Particle Vibro Shaker Machine

In order to choose the suitable model for you, please provide us the following information:
1. The name and feature of the raw material?
2. Aim of using: get rid of impurity, filtration or grading?
3. Handling capacity: kg /h, L/h?
4. Wire screen mesh size: (mesh or mm)?



if you are interested in our rotary sieve shaker for powder and particle, pls email or call us.

Should you be interested in our round medicine particle vibro shaker machine, please do not hesitate to contact us…… Round Medicine Particle Vibro Shaker Machine
