GMP Standard Round Medical Powder Vibrating Screen
- Shanghai Qingdao Lianyungang
- T/T Credit Card
You May Like
-
HY Medicine Powder Vibrator Mechanical Screen
-
China Circular Pharmaceutical Sieve Machine
-
High Quality Vibrating Sieve Separator Machine for Medical Industry
-
Stainless Steel Vibrating Screen With Small Volume
-
Stainless Steel Round Vibrating Sieve for Pharmacy
-
Rotary Vibrating Separating Sieve Equipment for Medicine
Product Details
| Place of Origin | Henan, China | Brand Name | HENG SHUN | |
| Model Number | HY-1000-2S | Application | Powder | |
| Type | Other, medical powder vibrating screen, medical powder vibrating screen | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
GMP standard round medical powder vibrating screen
6 years Gold Supplier certificated, 10 years in manufacturing experience
1. Learn about GMP standard round medical powder vibrating screen
Material: | Stainless steel 304 with contact parts |
Layer: | One layer, 2 outlets and separate raw materials into 2 levels |
Power source: | One set of vibration motor, 0.75KW |
Features: | 1. All- closed design of standard vibrating screen, no dust pollution. 2. High efficiency, both rough grading and fine screening can process. 3. Special screen design, easy to change(only need 3~5 minutes); long screen life of screen mesh, easy to clean. 4. The outlet's location can be adjusted to anywhere you need. |
Advantage: | Stainless steel standard vibrating screen do screening with help of bouncing ball |
OEM service: | Accepted |
Customization: | Accepted, dimension can be changed according to your working site. |
2. Picture of GMP standard round medical powder vibrating screen
3. Feature of GMP standard round medical powder vibrating screen
♦Dry separation
-Separation of different materials on the basis of their particle shape
-Foods, chemicals, pharmaceuticals, minerals, animal feeds, grains
♦ Dry classification
-Separation of solid particles into precise sized fractions
-Foods, chemicals, minerals and metals, pulp and wood products, pharmaceuticals, fertilizers, abrasives
♦ Solid-liquid separation
-Dewatering solids of liquids
-Foods, chemicals, pulp
♦ Solids classification in liquid medium
-Separation of solids into sized fraction in liquid medium
-Chemicals, minerals, pulp and paper, ceramics, waste disposal
4.Technical parameters of GMP standard round medical powder vibrating screen
Model | Diameter (mm) | Screen surface | Screen opening
| Power (KW) | Deck | |
Diameter | Area | |||||
(mm) | (m2) | |||||
HY-400 | 400 | 360 | 0.1017 | 5-500 mesh | 0.18 | 1-3 |
HY-600 | 600 | 560 | 0.2461 | 0.25-0.55 | 1-3 | |
HY-800 | 800 | 760 | 0.4534 | 0.55-0.75 | 1-3 | |
HY-1000 | 1000 | 930 | 0.6789 | 0.75-1.5 | 1-3 | |
HY-1200 | 1200 | 1130 | 1.0023 | 1.10-1.75 | 1-3 | |
HY-1500 | 1500 | 1430 | 1.6052 | 1.50-2.20 | 1-3 | |
HY-1800 | 1800 | 1730 | 2.3494 | 2.20-3.0 | 1-3 | |
5. Application for stainless steel of GMP standard round medical powder vibrating screen
6. More product details
7.Packing& Transportation
8. Why us
A. Award be man with feelings, do things with sinecrity, do business with credibility.
B. The professional manufacturer of vibrating sieve and conveying equipment over 10 years.
C. ISO9001:2008,CE and BV approved.
D. The unique patented technology.
E. Strong technical team
F. Well trained and skilful operators.
G. Accept cuatomer's special requirements.
H. Monthly production capacity: over 200 sets.
In future we adhere tohigh starting point of technology, high quality of service. In marketing, we wish to see development with friends from overseas and domestic on fair cooperation and mutual benefit.
9.Certifications
1>. How can I get your best offer before the order placing?
The more product request you provide, the more precise offer you will get.
Basic factors for an offer should have(including but no limitation): material name material density capacity screen size you need, etc.
2>. What it does?
Separate solids from liquids or segregate dry materials into various sizes.
3>. How it works?
Vibration is accomplished by eccentric weights on the upper and lower ends of the motion-generator shaft. and The angle of lead given the lower weight with relation to the upper weight provides variable control of the spiral screening pattern.
4>. Any self-cleaning devices on the sieving machine?
Yeah, Bouncing ball or Ultrasonic system could be installed.
5>. How many kinds of material are supported?
A. All stainless steel (201, 304, 316)
B. All carbon steel Q235A
C. Contact part Stainless steel.
6>. About the phase and the voltage?
0.12-0.55 kw single phase and three phase are both supported.
0.55-2.2 kw Three phase is just supported.
110V, 220V, 380V, 415V, 450V, 480V are supported. (50HZ OR 60 HZ).
7>. How long is the warranty?
The warranty is 12 month(except the wearing parts includes sealing strip, bounce ball and sieve mesh, etc.).
Because different usage, the wearing parts will have different life.
8>. OEM order and labeling services are supported?
Yeah, OEM order and labeling services are supported. And we seek global partners.
9>. Whether the factory visits is supported or not?
Yeah, factory visits will be highly welcome. Airport picking up and hotel booking are both supported.
One hour to both Xinzheng International Airport.
