oat vibrating screen with CE

 Structure

Technical Parameters

rotary vibro sieve own more advantages:

1. Can screen the particles of diameter up to635mesh ,and filter the serous fluid of diameter up to 500mesh
2. According to the applying requirements , at most four-layer screens with different mesh number can be installed on the screen, and separate into five particle groups of different diameters
3. Easy design and less power consumption but high efficiency
4. Longer life span of mesh screen and convenient to change it
5. Higher screening and separating efficiency

Show Some Pictures

A. Parts

------------------------------------------------------------------------------------------------------------------------------------------------

B. Different layer & different material

 -----------------------------------------------------------------------------------------------------------------------------------------------

C. Standard Accessories

D. Application

Chemical industry: resin pigment, medicine, grease, paint, palette, etc.

Abrasive material and ceramic industry: building sand, mica, alumina, abrasive, refractory material, slurry, etc.

Food industry: sugar, salt, alkali, gourmet powder, starch, milk powder, yeast powder, pollen, food additive, bean milk, juice, etc.

Metallurgy and mining industry: quartz sand, ore, titanium oxide, zinc oxide, etc.

Mechanical industry: casting sand, powder metallurgy, electromagnetic material and metal powder, etc.

E. Working Scene

---------------------------------------------- Packing & Shipping ---------------------------------------------------------

A. How To Delievery

--------------------------------------------Company Information------------------------------------------------------

A. Show Our Factory

B. Exhibition Pictures

C. Our Main Market

------------------------------------------------------------------------------------------------------------------------------------------------

Other vibrating screen for your reference

1. How can I get your best offer before the order placing?

The more product request you provide, the more precise offer you will get.

Basic factors for an offer should have(including but no limitation): material name material density capacity screen size you need, etc.

2. What it does?
Separate solids from liquids or segregate dry materials into various sizes.

3. How it works?
 Vibration is accomplished by eccentric weights on the upper and lower ends of the motion-generator shaft. and The angle of lead given the lower weight with relation to the upper weight provides variable control of the spiral screening pattern.

4. Any self-cleaning devices on the sieving machine?
Yeah, Bouncing ball or Ultrasonic system could be installed.

5. How many kinds of material are supported?
A. All stainless steel (201, 304, 316L)
B. All carbon steel Q235A
C. Contact part Stainless steel.

6. About the phase and the voltage?
0.12-0.55 kw single phase and three phase are both supported.
0.55-2.2 kw Three phase is just supported.
110V, 220V, 380V, 415V, 450V, 480V are supported. (50HZ OR 60 HZ).

7. How long is the warranty?
The warranty is 12 month(except the wearing parts includes sealing strip, bounce ball and sieve mesh, etc.).

Because different usage, the wearing parts will have different life.

8. OEM order and labeling services are supported?
Yeah, OEM order and labeling services are supported. And we seek global partners.

9. Whether the factory visits is supported or not?
Yeah, factory visits will be highly welcome. Airport picking up and hotel booking are both supported.

One hour to both Xinzheng International Airport
