Hengyu Ultrasonic Sieving Machine for Znic Powder

Hengyu Ultrasonic Sieving Machine for Znic Powder photo-1
US$ 1,500 - 5,600 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Circular
Application:
Other, Ultrasonic Sieving Machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Qingdao Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Circular
Application Other, Ultrasonic Sieving Machine
Place of Origin Henan, China
Brand Name HENG SHUN
Model Number HY-600-1S
Voltage 220v, 380v, 50hz, 60hz
Power(W) 0.25kw
Dimension(L*W*H) 800*800*750mm
Weight 180kg
Certification ISO9001:2008, CE, BV
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Ultrasonic Sieving Machine
2.Sieving ultra-fine powder
3.Automatic self-cleaning
4.Screening rate more than 95%



Hengyu Ultrasonic Sieving Machine for Znic Powder





This sieving machine adopts advanced intelligent ultrasonic controller .Has solved many problems

caused by single frequency. Truly achieving the combination of ultrasonic function and vibration sieve.

It has reached the highest international level.



More Features

Hengyu Ultrasonic Sieving Machine for Znic Powder

1. In achieving high precision and high mesh screening at the same time, control of a narrow size range.

2. Single or multilayer together screening, with a smart ultrasonic generator at the same time make

use of one transducers.

3. Ensure that the processing characteristics of the material unchanged.

4. Real solution to strong absorption, easy to join, high static, high-precision, high density, light weight and other screening problems.

5. Thoroughly screen self-cleaning function: greater than 500 mesh sieve, mesh-free jam, no attenuation of  screening efficiency.

6.1-70% can increase screening accuracy, output can be increased 0.5-10 times.



Technical Parameters
Hengyu Ultrasonic Sieving Machine for Znic Powder

Model

Power

Effective diameter

Dimensions(mm3)

Layer

HY-600

0.25KW

560 mm

800×800×750

1

800×800×890

2

HY-800

0.55KW

760 mm

900×900×750

1

900×900×890

2

HY-1000

0.75KW

930 mm

1160×1160×810

1

1160×1160×950

2

HY-1200

1.10KW

1130 mm

1360×1360×885

1

1360×1360×1050

2



Structure of Ultrasonic Sieving Machine

Hengyu Ultrasonic Sieving Machine for Znic Powder

Hengyu Ultrasonic Sieving Machine for Znic Powder



Pictures of Ultrasonic Sieving Machine

Hengyu Ultrasonic Sieving Machine for Znic Powder

Hengyu Ultrasonic Sieving Machine for Znic Powder

Hengyu Ultrasonic Sieving Machine for Znic Powder

Hengyu Ultrasonic Sieving Machine for Znic Powder



Quality assurance

Hengyu Ultrasonic Sieving Machine for Znic Powder

Quality assurance is the process of verifying or determining whether products or services meet or

exceed customer expectations. We use the following methods to ensure the quality of our products:

A.  Experienced staff

B.  Quality Control Department

C.  Third-party supervision

Our products passed the ISO9001:2008 and CE certificate



Hengyu Ultrasonic Sieving Machine for Znic Powder



Our service will be offered

Hengyu Ultrasonic Sieving Machine for Znic Powder

Hengyu Ultrasonic Sieving Machine for Znic Powder



The best way to be sure which machine is the best suits for your application, just need for telling four questions:
1. Name of your material?
2. Screen mesh you need?
3. How many Kg you handle per hour?
4. Other special demands?



If you are interested in our Ultrasonic Sieving Machine, pls email or call us.





  Hengyu Ultrasonic Sieving Machine for Znic Powder
