China Rotary Ultrasonic Sieve for High Density Powder

China Rotary Ultrasonic Sieve for High Density Powder photo-1
US$ 1,500 - 5,600 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Circular
Application:
Other, rotary ultrasonic sieve
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Qingdao Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Circular
Application Other, rotary ultrasonic sieve
Place of Origin Henan, China
Brand Name HENG SHUN
Model Number HY-600-1S
Voltage 220v, 380v, 50hz, 60hz
Power(W) 0.25kw
Dimension(L*W*H) 800*800*750mm
Weight 180kg
Certification ISO9001:2008, CE, BV
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas



China rotary ultrasonic sieve for high density powder





Let's know about rotary ultrasonic sieve by pictures


China rotary ultrasonic sieve for high density powder
China rotary ultrasonic sieve for high density powder

Screening demo of rotary ultrasonic sieve

China rotary ultrasonic sieve for high density powder

Technical Parameters of rotary ultrasonic sieve
China rotary ultrasonic sieve for high density powder

Model

Power

Effective diameter

Dimensions(mm3)

Layer

HY-600

0.25KW

560 mm

800×800×750

1

800×800×890

2

HY-800

0.55KW

760 mm

900×900×750

1

900×900×890

2

HY-1000

0.75KW

930 mm

1160×1160×810

1

1160×1160×950

2

HY-1200

1.10KW

1130 mm

1360×1360×885

1

1360×1360×1050

2



More Features

China rotary ultrasonic sieve for high density powder

1. In achieving high precision and high mesh screening at the same time, control of a narrow size range.

2. Single or multilayer together screening, with a smart ultrasonic generator at the same time make

use of one transducers.

3. Ensure that the processing characteristics of the material unchanged.

4.Real solution to strong absorption, easy to join, high static, high-precision, high density, light weight and other screening problems.

5. Thoroughly screen self-cleaning function: greater than 500 mesh sieve, mesh-free jam, no attenuation of  screening efficiency.

6.1-70% can increase screening accuracy, output can be increased 0.5-10 times.



Structure of rotary ultrasonic sieve



China rotary ultrasonic sieve for high density powder



---------------------------------Certificate and Service---------------------------------------------



Quality assurance

China rotary ultrasonic sieve for high density powder

Quality assurance is the process of verifying or determining whether products or services meet or

exceed customer expectations. We use the following methods to ensure the quality of our products:

A.  Experienced staff

B.  Quality Control Department

C.  Third-party supervision

Our products passed the ISO9001:2008 and CE certificate

China rotary ultrasonic sieve for high density powder



Best service



China rotary ultrasonic sieve for high density powder



The best way to be sure which rotary ultrasonic sieve is the best suits for your application, just need for telling four questions:
1. Name of your material?
2. Screen mesh you need?
3. How many Kg you handle per hour?
4. Other special demands?



If you are interested in our rotary ultrasonic sieve, pls email or call us.



Tel:86-373-3807161    Mobile:86-159 3737 6329   Skype:lane-li
