Specifications
TX-006 brass tube
Gardes T2 percentage of copper:99.99%
TX-006 brass tube
OutsideDiameter | From 6 To 220 |
Thickness | From 0.6 To 6.0 |
Material: red copper
Gardes T2 percentage of copper:99.99%
Gardes T3: percentage of copper:99.97%
Diameter Range: 15mm----300mm
Max Length:3000mm
Shape: 1.Hexagonal, 2.Square, 3.Round
Apllication: 1.cutting mouth/conductive mouth 2.quicker connector 3.Electrode
4.All kinds of easy cutting copper parts
Specifications
1) Heat conduction
2) Excellent freezing
3) Even structure with pressure resistance
4) Good mechanical proper
Copper pipe
1.Manufacturer
2.Cu>99.95%
3.TP2/EN/ASTM
4.Quality grade A
Nominal Standard Size inch | Outside Diameter inch | Wall thickness and tolerances(inch) | calculated Weight 1b/ft | |||||||
Type K | K | Type L | L | Type M | M | Type K | Type L | Type M | ||
WT | Tolerance | WT | Tolerance | WT | Tolerance | |||||
1/4" | 0.375 | 0.035 | 0.0035 | 0.030 | 0.003 | - | - | 0.145 | 0.126 | - |
3/8" | 0.500 | 0.049 | 0.005 | 0.035 | 0.004 | 0.025 | 0.002 | 0.269 | 0.198 | 0.145 |
1/2" | 0.625 | 0.049 | 0.005 | 0.040 | 0.004 | 0.028 | 0.003 | 0.344 | 0.285 | 0.204 |
5/8" | 0.750 | 0.049 | 0.005 | 0.042 | 0.004 | - | - | 0.418 | 0.362 | - |
3/4" | 0.875 | 0.065 | 0.006 | 0.045 | 0.004 | 0.032 | 0.003 | 0.641 | 0.455 | 0.328 |
1" | 1.125 | 0.065 | 0.006 | 0.050 | 0.005 | 0.035 | 0.004 | 0.839 | 0.655 | 0.465 |
11/4" | 1.375 | 0.065 | 0.006 | 0.055 | 0.006 | 0.042 | 0.004 | 1.04 | 0.884 | 0.682 |
11/2" | 1.625 | 0.072 | 0.007 | 0.060 | 0.006 | 0.049 | 0.005 | 1.36 | 1.14 | 0.940 |
Listed below are the properties of the Copper pipes tubes manufactured by us that are ideal for heating applications:
Physical Properties: | ||
| ||
Temper | Tensile strength Kg/mm2 Min. | Elongation % on 5.65 A Min. |
Annealed | 21.5 | 33 |
As Manufactured | 23.5 | 13 |
Chemical Requirements: | |
| |
Copper (Incl. Silver) | 99.85% Min. |
Phosphorus | 0.013 to 0.05% |
Total Impurities | 0.06% Max. |
