350L-750L friction transmissionJZC, JZM Concrete Mixer
Descriptions of JZC, JZM Concrete Mixer:
JZC, JZM series mixer is a gravity type of double-conic reversing drum concrete mixer, the drum transit by gear or friction wheel, the drum rotates clockwise during mixing and anti-clockwise during discharging. It is portable and movable. The mixer can mix plasticity and damp half-dry concrete. These mixer services for ordinary construction site, roads, bridge projects and precast plant.
Technical Parameters of JZC, JZM Concrete Mixer:
|
JZC250 |
JZC350 |
JZM350 |
JZC500 |
JZC750 |
Discharge Volume(L) |
250 |
350 |
350 |
500 |
750 |
Charge Volume(L) |
320 |
560 |
560 |
800 |
1200 |
Productivity(m3/h) |
6-8 |
10-14 |
13 |
18-20 |
20-22 |
Rotation speed(r/min) |
17 |
14 |
15 |
13 |
13 |
Max. aggregate size(mm) |
60 |
60 |
60 |
60-80 |
60-80 |
Water supply accuracy |
+/-≤2% |
+/-≤2% |
+/-≤2% |
+/-≤2% |
+/-≤2% |
Mixing motor(kw) |
4 |
5.5 |
5.5 |
11 |
15 |
Lifting motor(kw) |
4 |
4.5 |
4.5 |
5.5 |
7.5 |
Water pump motor (kw) |
0.55 |
0.55 |
0.55 |
0.75 |
1.1 |
tyre |
6.50-16 |
6.50-16 |
6.50-16 |
7.50-16 |
|
Max. drag speed(km/h) |
20 |
20 |
20 |
20 |
|
Overall size(L×W×H)(mm) |
2260×1990×2750 |
2766×2140×3000 |
3800×2050×2690 |
5226×2200×5460 |
6116×2056×6060 |
Weight(kg) |
1300 |
1950 |
1970 |
3100 |
4200 |
