JZM750 Concrete Drum Mixer
Specifications
JZM750 concrete drum mixercompetitive price,
short lead time,
high quality.
ISO9001 and CE certified.
JZM750 concrete drum mixer
JZC JZM concrete mixer machines is the reversal mixer machines, the mixer canister is drove by the tooth circle. When it works, if you veer turn is mixing, and reversal turn is output material. It can mixer the plastic and the half dry hard concrete. And it is the ideal machines for construction fields, road, bridge project and all kinds of concrete parts factory. JZC series mixer includes JZC250, 350, 500, 750 and JZM350. All the machines are portable type except JZC750 is stationary one.
Model |
JZM 750 |
|
Discharge capacity |
750L |
|
Charge capacity |
1200L |
|
Capacity |
30-35m3/h |
|
Mixing motor power |
11 kw |
|
Lifting motor power |
7.5 kw |
|
Pump capacity |
0.75 kw |
|
Water supply accuracy |
≤2% |
|
Drum rotating speed |
12.26r/min |
|
Max aggregate size |
80mm |
|
Dimension |
Travel state |
3680*3065*3565 mm |
Operation state |
5650*2065*3535 mm |
|
weight |
4000 kg |
|
