Home > Manufacturing & Processing Machinery > Mixing Equipment > Concrete Mixer > JZC/JZM Gravity Type Concrete Mixer

JZC/JZM Gravity Type Concrete Mixer

Name: JZC/JZM Gravity Type Concrete Mixer
Brand: UNIQUE
SKU: 138877815

JZC/JZM Gravity Type Concrete Mixer thumbnail-1

JZC/JZM Gravity Type Concrete Mixer photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Henan, China

Brand Name:

UNIQUE

Contact Supplier Request Quote Chat Now

Zhengzhou Unique Industrial Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QingDao port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Henan, China

Brand Name UNIQUE

Model Number JZC&JZM Series

Discharge Way Reverse Rotation

Specifications

JZC/JZM Gravity Type Concrete Mixer is portable and movable. The mixer can mix plasticity and damp half-dry concrete.

JZC/JZM Gravity Type Concrete Mixer

Descriptions:

JZC, JZM series mixer is a gravity type of double-conic reversing drum concrete mixer, the drum transit by gear or friction wheel, the drum rotates clockwise during mixing and anti-clockwise during discharging. It is portable and movable. The mixer can mix plasticity and damp half-dry concrete. These mixer services for ordinary construction site, roads, bridge projects and precast plant.

Technical Parameters of JZC, JZM Concrete Mixer:

Model	JZC350	JZC500	JZM500	JZM750
Discharge volume	350L	500L	500L	750L
Charging volume	560L	800L	800L	1200L
Capacity	10~14 m³/h	18~20 m³/h	25~30 m³/h	30~35 m³/h
Aggregate sizes	≤60m	≤60mm	≤70mm	≤80mm
Rotating speed	14 r/min	13 r/min	13 r/min	12.26 r/min
Max. drag speed	20km/h	20km/h	/	/
Mixing motor	5.5kw	7.5kw	7.5kw	11kw
Lifting motor	4.5KW	5.5kw	5.5kw	7.5kw
Pump motor	0.55kw	0.55kw	0.75kw	0.75kw
Weight	1950kg	2400kg	3000kg	4000kg
Dimensions (L x W x H)mm	2766x2140x3000	3500x2200x3200	5200x2065x3200	5650x2065x3535
