Specifications
JZC Concrete Mixer1.CE&ISO certificated
2.rational structure,high production efficiency,excellent mixing quality,best service
On Sale Super Performance JZC Concrete Mixer
Description of JZC Concrete Mixer:
JZC Concrete Mixer, as a gravity type of double-conic reversing drum concrete mixer, the drum transmits by gear of friction wheel. The drum rotates clockwise during mixing and anticlockwise during discharging. The mixer can mix plasticity and damp half-dry concrete. It is usually used on ordinary construction sites, roads, bridges projects and concrete prefabricated parts factories.
This type of mixer is designed and manufactured according to GB/T9142-2000 <>. It has rational structure, and has the advantages of high production efficiency,excellent mixing quality, artistic outlook, light weight and convenience moving.
Technical Parameters of JZC Concrete Mixer:
Model | JZC250 | JZC350 | JZC400 | JZC450 | JZC500 | JZC750 |
Discharge volume | 250L | 350L | 400 | 450 | 500L | 750L |
Charging volume | 320L | 560L | 640 | 720 | 800L | 1200L |
Capacity | 6~8 m3/h | 10~14 m3/h | 12~16 m3/h | 14~18 m3/h | 18~20 m3/h | 30-35m3/h |
Rotating speed | 17 r/min | 14 r/min | 14 r/min | 14 r/min | 13 r/min | 12.26r/min |
Mixing motor | 4kw | 5.5kw | 7.5kw | 7.5kw | 7.5kw | 11kw |
Hoisting motor | 4KW | 4.5KW | 4.5kw | 4.5kw | 5.5kw | 7.5kw |
Pump motor | 0.55kw | 0.55kw | 0.55kw | 0.55kw | 0.55kw | 0.55kw |
Max. aggregate size | 60mm | 60mm | 40~60mm | 40~60mm | 60~80mm | 60~80mm |
Hopper lifting speed | 8m/min | 8m/min | 8m/min | 8m/min | 8m/min | 8m/min |
