Specifications
concrete mixer in dubai1.Lower price !
2.Experienced for 15 years !
3.ISO9001 & CE !
4.good mixer effect
concrete mixer in dubai
Introduction of concrete mixer in dubai:
JZC series Concrete Mixer is the hopper feeding concrete mixer with one mixing motor and one lifting motor.
The concrete mixer hopper is feeding the material by the cone-shape motor transmission, the up and down of the hopper and the stir bin turn and reversal is controlled by the electrical appliance.
Advantages of concrete mixer in dubai :
This machine has reasonable structure, smooth running , easy control , good quality of mixing, high productivity, high automatic advantage. It can mix plastic and half-hard concrete, it suits general construction site, road, bridge, and Hydroelectric power projects and some small and middle concrete component factory.
Working principles of concrete mixer in dubai :
The machine mixes when the double-cone mixer drum rotates clockwise and discharges when it rotates reversally. The mixer drum is driven by the ring gear.
Technical parameters of concrete mixer in dubai :
Model |
JZC250 |
|
JZC350 |
JZC500 |
Discharge volume |
250L |
|
350L |
500L |
Charging volume |
320L |
|
560L |
800L |
Capacity |
6~8 m3/h |
|
10~14 m3/h |
18~20 m3/h |
Rotating speed |
17 r/min |
|
14 r/min |
13 r/min |
Mixing motor |
4kw |
|
5.5kw |
7.5kw |
Lifting motor |
4KW |
|
4.5KW |
5.5kw |
Pump motor |
0.55kw |
|
0.55kw |
0.55kw |
Weight |
1500kg |
|
1950kg |
2400kg |
Dimensions (L x W x H) |
2260x1990x2750 mm |
|
2766x2140x3000 mm |
3500x2200x3200 mm |
Our factory:
Our certifications of electric beton mixer :
Welcome your inquiry!
